| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Part Status | Capacitance | Tolerance | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Surface Mount Land Size | Polarization | Ratings | Voltage - Rated | Part Applications | Ripple Current @ Low Frequency | Height - Seated (Max) | Ripple Current @ High Frequency | Mounting Style | Size / Dimension | Impedance | Lead Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CGS103U075V4CCAP ALUM 10000UF 75V SCREW CHAS Cornell Dubilier Knowles |
9 |
|
Datasheet |
CGS | Bulk | Active | 10000 µF | -10%, +75% | 24mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | Polar | - | 75 V | General Purpose | 9 A @ 120 Hz | 4.125" (104.78mm) | 11.7 A @ 10 kHz | Chassis Mount | 2.000" Dia (50.80mm) | - | - | |
|
DCMX812T100BB2BCAP ALUM 8100UF 100V SCREW CHAS Cornell Dubilier Knowles |
46 |
|
Datasheet |
DCMX | Bulk | Active | 8100 µF | -10%, +50% | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | Polar | - | 100 V | General Purpose | - | 3.187" (80.95mm) | - | Chassis Mount | 2.000" Dia (50.80mm) | - | 0.875" (22.23mm) | |
|
MLP112M100EK0ACAP ALUM 1100UF 20% 100V FLATPAC Cornell Dubilier Knowles |
60 |
|
Datasheet |
MLP | Bulk | Active | 1100 µF | ±20% | 112mOhm | 2000 Hrs @ 85°C | -55°C ~ 85°C | - | - | - | 100 V | General Purpose | - | 0.500" (12.70mm) | - | Chassis Mount | 1.500" L x 1.750" W (38.10mm x 44.45mm) | - | 1.000" (25.40mm) | |
|
CGS551T250R4CCAP ALUM 550UF 250V SCREW CHAS M Cornell Dubilier Knowles |
46 |
|
Datasheet |
CGS | Bulk | Active | 550 µF | -10%, +50% | 98mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | Polar | - | 250 V | General Purpose | 3.6 A @ 120 Hz | 4.125" (104.78mm) | 5.4 A @ 10 kHz | Chassis Mount | 1.375" Dia (34.93mm) | - | - | |
|
|
500C103T100BJ2BCAP ALUM 10000UF 100V SCREW CHAS Cornell Dubilier Knowles |
43 |
|
Datasheet |
500C | Bulk | Active | 10000 µF | -10%, +50% | 23mOhm @ 120Hz | 5000 Hrs @ 95°C | -40°C ~ 95°C | - | Polar | - | 100 V | General Purpose | - | 3.625" (92.08mm) | - | Chassis Mount | 2.000" Dia (50.80mm) | - | 0.874" (22.20mm) | |
|
CGS103U035V2CCAP ALUM 10000UF 35V SCREW CHAS Cornell Dubilier Knowles |
5 |
|
Datasheet |
CGS | Bulk | Active | 10000 µF | -10%, +75% | 38mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | Polar | - | 35 V | General Purpose | 5.5 A @ 120 Hz | 2.125" (53.98mm) | 7.15 A @ 10 kHz | Chassis Mount | 2.000" Dia (50.80mm) | - | - | |
|
CGS353U040V5LCAP ALUM 35000UF 40V SCREW CHAS Cornell Dubilier Knowles |
34 |
|
Datasheet |
CGS | Bulk | Active | 35000 µF | -10%, +75% | 15mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | Polar | - | 40 V | General Purpose | 12.8 A @ 120 Hz | 5.625" (142.88mm) | 16.64 A @ 10 kHz | Chassis Mount | 2.000" Dia (50.80mm) | - | - | |
|
CGS153U050V4CCAP ALUM 15000UF 50V SCREW CHAS Cornell Dubilier Knowles |
104 |
|
Datasheet |
CGS | Bulk | Active | 15000 µF | -10%, +75% | 19mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | Polar | - | 50 V | General Purpose | 10 A @ 120 Hz | 4.125" (104.78mm) | 13 A @ 10 kHz | Chassis Mount | 2.000" Dia (50.80mm) | - | 0.875" (22.22mm) | |
|
|
CGS103U100W4CCAP ALUM 10000UF 100V SCREW CHAS Cornell Dubilier Knowles |
48 |
|
Datasheet |
CGS | Bulk | Active | 10000 µF | -10%, +75% | 40mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | Polar | - | 100 V | General Purpose | 8 A @ 120 Hz | 4.125" (104.78mm) | 10.4 A @ 10 kHz | Chassis Mount | 2.500" Dia (63.50mm) | - | 1.125" (28.58mm) | |
|
CGS183U100V4CCAP ALUM 18000UF 100V SCREW CHAS Cornell Dubilier Knowles |
32 |
|
Datasheet |
CGS | Bulk | Active | 18000 µF | -10%, +75% | 18mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | Polar | - | 100 V | General Purpose | 10.5 A @ 120 Hz | 4.125" (104.78mm) | 13.65 A @ 10 kHz | Chassis Mount | 2.000" Dia (50.80mm) | - | - |
