Aluminum - Polymer Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Ratings | Applications | Features | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PCR0J272MCL1GSCAP ALUM POLY 2700UF 20% 6.3V Nichicon |
3,395 |
|
Datasheet |
PCR | Tape & Reel (TR) | Obsolete | Polymer | 2700 µF | ±20% | 6.3 V | 11mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | - | 4.7 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.500" (12.70mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
PLX1C391MDL1TDCAP ALUM POLY 390UF 20% 16V TH Nichicon |
2,120 |
|
Datasheet |
PLX | Cut Tape (CT) | Active | Polymer | 390 µF | ±20% | 16 V | 23mOhm | 3000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | - | 2.9 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
PCX1V680MCS1GSCAP ALUM POLY 68UF 20% 35V SMD Nichicon |
3,655 |
|
Datasheet |
PCX | Tape & Reel (TR) | Active | Polymer | 68 µF | ±20% | 35 V | 30mOhm | 3000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | - | 2.2 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.433" (11.00mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
PLV2A100MDL1TDCAP ALUM POLY 10UF 20% 100V TH Nichicon |
3,847 |
|
Datasheet |
PLV | Cut Tape (CT) | Obsolete | Polymer | 10 µF | ±20% | 100 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.8 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | - | Through Hole |
|
PLV2A180MDL1TDCAP ALUM POLY 18UF 20% 100V TH Nichicon |
3,454 |
|
Datasheet |
PLV | Cut Tape (CT) | Obsolete | Polymer | 18 µF | ±20% | 100 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.2 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
|
PLV1K220MDL1CAP ALUM POLY 22UF 20% 80V TH Nichicon |
6 |
|
Datasheet |
PLV | Bulk | Discontinued at Digi-Key | Polymer | 22 µF | ±20% | 80 V | 35mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.3 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
|
PLV1E121MDL1CAP ALUM POLY 120UF 20% 25V TH Nichicon |
4,235 |
|
Datasheet |
PLV | Bulk | Obsolete | Polymer | 120 µF | ±20% | 25 V | 25mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.8 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
PLV1V270MCL1CAP ALUM POLY 27UF 20% 35V TH Nichicon |
3,588 |
|
Datasheet |
PLV | Bulk | Obsolete | Polymer | 27 µF | ±20% | 35 V | 42mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.6 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
|
|
PLV1V680MDL1CAP ALUM POLY 68UF 20% 35V TH Nichicon |
3,237 |
|
Datasheet |
PLV | Bulk | Obsolete | Polymer | 68 µF | ±20% | 35 V | 28mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.7 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
|
PLV1H470MDL1CAP ALUM POLY 47UF 20% 50V TH Nichicon |
3,421 |
|
Datasheet |
PLV | Bulk | Obsolete | Polymer | 47 µF | ±20% | 50 V | 31mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.5 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.512" (13.00mm) | - | Through Hole |
