FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NP45N06PUK-E1-AYMOSFET N-CH 60V 45A TO263 |
6,401 |
|
Datasheet |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 45A (Tc) | 10V | 9.6mOhm @ 23A, 10V | 4V @ 250µA | 45 nC @ 10 V | ±20V | 2540 pF @ 25 V | - | 1.2W (Ta), 75W (Tc) | 175°C | Automotive | AEC-Q101 | Surface Mount | TO-263-3 |
|
SQD25N06-22L_GE3MOSFET N-CH 60V 25A TO252 |
3,760 |
|
Datasheet |
TrenchFET® | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 25A (Tc) | 4.5V, 10V | 22mOhm @ 20A, 10V | 2.5V @ 250µA | 50 nC @ 10 V | ±20V | 1975 pF @ 25 V | - | 62W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-252AA |
|
CSD17576Q5BTMOSFET N-CH 30V 100A 8VSON |
477 |
|
Datasheet |
NexFET™ | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 100A (Ta) | 4.5V, 10V | 2mOhm @ 25A, 10V | 1.8V @ 250µA | 32 nC @ 4.5 V | ±20V | 4430 pF @ 15 V | - | 3.1W (Ta), 125W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-VSONP (5x6) |
|
TSM043NH04LCR RLG40V, 54A, SINGLE N-CHANNEL POWER |
4,000 |
|
Datasheet |
PerFET™ | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 20A (Ta), 54A (Tc) | 4.5V, 10V | 4.3mOhm @ 27A, 10V | 2.2V @ 250µA | 42 nC @ 10 V | ±16V | 2480 pF @ 25 V | - | 100W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount, Wettable Flank | 8-PDFNU (5x6) |
|
IPB80N04S404ATMA1MOSFET N-CH 40V 80A TO263-3-2 |
1,989 |
|
Datasheet |
OptiMOS™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 80A (Tc) | 10V | 4.2mOhm @ 80A, 10V | 4V @ 35µA | 43 nC @ 10 V | ±20V | 3440 pF @ 25 V | - | 71W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | PG-TO263-3-2 |
|
STP3N80K5MOSFET N-CH 800V 2.5A TO220 |
1,841 |
|
Datasheet |
SuperMESH5™ | TO-220-3 | Tube | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 800 V | 2.5A (Tc) | 10V | 3.5Ohm @ 1A, 10V | 5V @ 100µA | 9.5 nC @ 10 V | ±30V | 130 pF @ 100 V | - | 60W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 |
|
STD18N60M6MOSFET N-CH 600V 13A DPAK |
1,612 |
|
Datasheet |
MDmesh™ M6 | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 13A (Tc) | 10V | 280mOhm @ 6.5A, 10V | 4.75V @ 250µA | 16.8 nC @ 10 V | ±25V | 650 pF @ 100 V | - | 110W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252 (DPAK) |
|
R6504END3TL1650V 4A TO-252, LOW-NOISE POWER |
1,246 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 4A (Tc) | 10V | 1.05Ohm @ 1.5A, 10V | 4V @ 130µA | 15 nC @ 10 V | ±20V | 220 pF @ 25 V | - | 58W (Tc) | 150°C | - | - | Surface Mount | TO-252 |
|
|
SIHB6N80AE-GE3E SERIES POWER MOSFET D2PAK (TO- |
1,040 |
|
Datasheet |
E | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 5A (Tc) | 10V | 950mOhm @ 2A, 10V | 4V @ 250µA | 22.5 nC @ 10 V | ±30V | 422 pF @ 100 V | - | 62.5W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
|
|
IPB80N04S4L04ATMA1MOSFET N-CH 40V 80A TO263-3 |
661 |
|
Datasheet |
OptiMOS™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 80A (Tc) | 4.5V, 10V | 4mOhm @ 80A, 10V | 2.2V @ 35µA | 60 nC @ 10 V | +20V, -16V | 4690 pF @ 25 V | - | 71W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | PG-TO263-3-2 |
|
PJMF580N60E1_T0_00001600V SUPER JUNCITON MOSFET |
1,952 |
|
Datasheet |
- | TO-220-3 Full Pack, Isolated Tab | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 8A (Tc) | 10V | 580mOhm @ 2.5A, 10V | 4V @ 250µA | 15 nC @ 10 V | ±30V | 497 pF @ 400 V | - | 28W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | ITO-220AB-F |
;;2.jpg)
|
STD13N65M2MOSFET N-CH 650V 10A DPAK |
1,710 |
|
Datasheet |
MDmesh™ M2 | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 10A (Tc) | 10V | 430mOhm @ 5A, 10V | 4V @ 250µA | 17 nC @ 10 V | ±25V | 590 pF @ 100 V | - | 110W (Tc) | 150°C (TJ) | - | - | Surface Mount | DPAK |
|
|
IRFR1N60ATRPBF-BE3MOSFET N-CH 600V 1.4A DPAK |
1,869 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 1.4A (Tc) | - | 7Ohm @ 840mA, 10V | 4V @ 250µA | 14 nC @ 10 V | ±30V | 229 pF @ 25 V | - | 36W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252AA |
|
IXFA36N20X3MOSFET N-CH 200V 36A TO263AA |
185 |
|
Datasheet |
HiPerFET™, Ultra X3 | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 36A (Tc) | 10V | 45mOhm @ 18A, 10V | 4.5V @ 500µA | 21 nC @ 10 V | ±20V | 1425 pF @ 25 V | - | 176W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-263AA (IXFA) |
|
AOD7S65MOSFET N-CH 650V 7A TO252 |
2,492 |
|
Datasheet |
aMOS™ | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 650 V | 7A (Tc) | 10V | 650mOhm @ 3.5A, 10V | 4V @ 250µA | 9.2 nC @ 10 V | ±30V | 434 pF @ 100 V | - | 89W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252 (DPAK) |
|
TK7P65W,RQMOSFET N-CH 650V 6.8A DPAK |
908 |
|
Datasheet |
DTMOSIV | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 6.8A (Ta) | 10V | 800mOhm @ 3.4A, 10V | 3.5V @ 250µA | 15 nC @ 10 V | ±30V | 490 pF @ 300 V | - | 60W (Tc) | 150°C (TJ) | - | - | Surface Mount | DPAK |
|
AOT7S65LMOSFET N-CH 650V 7A TO220 |
373 |
|
Datasheet |
aMOS™ | TO-220-3 | Tube | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 650 V | 7A (Tc) | 10V | 650mOhm @ 3.5A, 10V | 4V @ 250µA | 9.2 nC @ 10 V | ±30V | 434 pF @ 100 V | - | 104W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 |
|
NP16N06YLL-E1-AYABU / MOSFET |
4,751 |
|
Datasheet |
- | 8-PowerLDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 16A (Tc) | 4.5V, 10V | 35mOhm @ 8A, 10V | 2V @ 1mA | 18 nC @ 10 V | ±20V | 600 pF @ 25 V | - | 1.25W (Ta), 27.3W (Tc) | 175°C | - | - | Surface Mount | 8-HSON (5x5.4) |
|
IRF730PBF-BE3MOSFET N-CH 400V 5.5A TO220AB |
2,982 |
|
Datasheet |
- | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 400 V | 5.5A (Tc) | 10V | 1Ohm @ 3A, 10V | 4V @ 250µA | 38 nC @ 10 V | ±20V | 700 pF @ 25 V | - | 74W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220AB |
|
AOTF286LMOSFET N-CH 80V 13.5A/56A TO220 |
2,270 |
|
Datasheet |
- | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 13.5A (Ta), 56A (Tc) | 6V, 10V | 6mOhm @ 20A, 10V | 3.3V @ 250µA | 63 nC @ 10 V | ±20V | 3142 pF @ 40 V | - | 2.2W (Ta), 37.5W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220F |
