FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RJ1G12BGNTLLMOSFET N-CH 40V 120A LPTL |
664 |
|
Datasheet |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 40 V | 120A (Tc) | 4.5V, 10V | 1.86mOhm @ 50A, 10V | 2.5V @ 2mA | 165 nC @ 10 V | ±20V | 12500 pF @ 20 V | - | 178W (Tc) | 150°C (TJ) | - | - | Surface Mount | LPTL |
|
IRFP260PBFMOSFET N-CH 200V 46A TO247-3 |
292 |
|
Datasheet |
- | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 46A (Tc) | 10V | 55mOhm @ 28A, 10V | 4V @ 250µA | 230 nC @ 10 V | ±20V | 5200 pF @ 25 V | - | 280W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AC |
|
IPW65R110CFD7XKSA1HIGH POWER_NEW |
221 |
|
Datasheet |
CoolMOS™ CFD7 | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 22A (Tc) | 10V | 110mOhm @ 9.7A, 10V | 4.5V @ 480µA | 41 nC @ 10 V | ±20V | 1942 pF @ 400 V | - | 114W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | PG-TO247-3 |
|
STF33N60DM2MOSFET N-CH 650V 24A TO220FP |
3,643 |
|
Datasheet |
MDmesh™ DM2 | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 24A (Tc) | 10V | 130mOhm @ 12A, 10V | 5V @ 250µA | 43 nC @ 10 V | ±25V | 1870 pF @ 100 V | - | 35W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220FP |
|
SIHA17N80E-GE3N-CHANNEL 800V |
1,980 |
|
Datasheet |
E | TO-220-3 Full Pack | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 6A (Tc) | 10V | 290mOhm @ 8.5A, 10V | 4V @ 250µA | 122 nC @ 10 V | ±30V | 2408 pF @ 100 V | - | 35W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 Full Pack |
|
IPB60R099C7ATMA1MOSFET N-CH 600V 22A TO263-3 |
1,000 |
|
Datasheet |
CoolMOS™ C7 | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 22A (Tc) | 10V | 99mOhm @ 9.7A, 10V | 4V @ 490µA | 42 nC @ 10 V | ±20V | 1819 pF @ 400 V | - | 110W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-TO263-3-2 |
|
NTP150N65S3HFMOSFET N-CH 650V 24A TO220-3 |
745 |
|
Datasheet |
FRFET®, SuperFET® III | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 24A (Tc) | 10V | 150mOhm @ 12A, 10V | 5V @ 540µA | 43 nC @ 10 V | ±30V | 1985 pF @ 400 V | - | 192W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220-3 |
|
R6020KNXC7G600V 20A TO-220FM, HIGH-SPEED SW |
769 |
|
Datasheet |
- | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 20A (Tc) | 10V | 196mOhm @ 9.5A, 10V | 5V @ 1mA | 40 nC @ 10 V | ±20V | 1550 pF @ 25 V | - | 68W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220FM |
|
|
SIHG125N60EF-GE3MOSFET N-CH 600V 25A TO247AC |
500 |
|
Datasheet |
EF | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 25A (Tc) | 10V | 125mOhm @ 12A, 10V | 5V @ 250µA | 47 nC @ 10 V | ±30V | 1533 pF @ 100 V | - | 179W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AC |
|
FDBL0090N40MOSFET N-CH 40V 240A 8HPSOF |
200 |
|
Datasheet |
PowerTrench® | 8-PowerSFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 240A (Tc) | 10V | 0.9mOhm @ 80A, 10V | 4V @ 250µA | 188 nC @ 10 V | ±20V | 12000 pF @ 25 V | - | 357W (Tj) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | 8-HPSOF |
|
STH320N4F6-6MOSFET N-CH 40V 200A H2PAK-6 |
976 |
|
Datasheet |
DeepGATE™, STripFET™ VI | TO-263-7, D2PAK (6 Leads + Tab) | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 200A (Tc) | 10V | 1.3mOhm @ 80A, 10V | 4V @ 250µA | 240 nC @ 10 V | ±20V | 13800 pF @ 15 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | H2PAK-6 |
|
R6024VNXC7G600V 13A TO-220FM, PRESTOMOS WIT |
1,070 |
|
Datasheet |
- | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 13A (Tc) | 10V, 15V | 153mOhm @ 6A, 15V | 6.5V @ 700µA | 38 nC @ 10 V | ±30V | 1800 pF @ 100 V | - | 70W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220FM |
|
STB35N65DM2MOSFET N-CH 650V 28A D2PAK |
971 |
|
Datasheet |
MDmesh™ M2 | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 28A (Tc) | 10V | 110mOhm @ 14A, 10V | 5V @ 250µA | 54 nC @ 10 V | ±25V | 2400 pF @ 100 V | - | 210W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | D2PAK |
|
|
IXTP24N65X2MOSFET N-CH 650V 24A TO220AB |
259 |
|
Datasheet |
Ultra X2 | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 24A (Tc) | 10V | 145mOhm @ 12A, 10V | 5V @ 250µA | 36 nC @ 10 V | ±30V | 2060 pF @ 25 V | - | 390W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220-3 |
|
IPL60R085P7AUMA1MOSFET N-CH 600V 39A 4VSON |
238 |
|
Datasheet |
CoolMOS™ P7 | 4-PowerTSFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 39A (Tc) | 10V | 85mOhm @ 11.8A, 10V | 4V @ 590µA | 51 nC @ 10 V | ±20V | 2180 pF @ 400 V | - | 154W (Tc) | -40°C ~ 150°C (TJ) | - | - | Surface Mount | PG-VSON-4 |
|
STB9NK90ZMOSFET N-CH 900V 8A D2PAK |
680 |
|
Datasheet |
SuperMESH™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 900 V | 8A (Tc) | 10V | 1.3Ohm @ 3.6A, 10V | 4.5V @ 100µA | 72 nC @ 10 V | ±30V | 2115 pF @ 25 V | - | 160W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | D2PAK |
|
|
IXTP86N20TMOSFET N-CH 200V 86A TO220AB |
346 |
|
Datasheet |
Trench | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 86A (Tc) | 10V | 29mOhm @ 500mA, 10V | 5V @ 1mA | 90 nC @ 10 V | ±30V | 4500 pF @ 25 V | - | 480W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220-3 |
|
R8008ANJFRGTLMOSFET N-CH 800V 8A LPTS |
970 |
|
Datasheet |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 8A (Tc) | 10V | 1.03Ohm @ 4A, 10V | 5V @ 1mA | 38 nC @ 10 V | ±30V | 1100 pF @ 25 V | - | 195W (Tc) | 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | LPTS |
|
SUP40N25-60-E3MOSFET N-CH 250V 40A TO220AB |
466 |
|
Datasheet |
TrenchFET® | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 250 V | 40A (Tc) | 6V, 10V | 60mOhm @ 20A, 10V | 4V @ 250µA | 140 nC @ 10 V | ±30V | 5000 pF @ 25 V | - | 3.75W (Ta), 300W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220AB |
|
TK28V65W,LQX35 PB-F POWER MOSFET TRANSISTOR |
4,966 |
|
Datasheet |
- | 4-VSFN Exposed Pad | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 27.6A (Ta) | 10V | 120mOhm @ 13.8A, 10V | 3.5V @ 1.6mA | 75 nC @ 10 V | ±30V | 3000 pF @ 300 V | - | 240W (Tc) | 150°C | - | - | Surface Mount | 4-DFN-EP (8x8) |
