FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FDMS86202MOSFET N-CH 120V 13.5A POWER56 |
2,684 |
|
Datasheet |
PowerTrench® | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 120 V | 13.5A (Ta) | 6V, 10V | 7.2mOhm @ 13.5A, 10V | 4V @ 250µA | 64 nC @ 10 V | ±20V | 4250 pF @ 60 V | - | 2.7W (Ta), 156W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-PQFN (5x6) |
|
STF38N65M5MOSFET N-CH 650V 30A TO220FP |
1,708 |
|
Datasheet |
MDmesh™ V | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 30A (Tc) | 10V | 95mOhm @ 15A, 10V | 5V @ 250µA | 71 nC @ 10 V | ±25V | 3000 pF @ 100 V | - | 35W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220FP |
|
IPB60R080P7ATMA1MOSFET N-CH 600V 37A D2PAK |
1,559 |
|
Datasheet |
CoolMOS™ P7 | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 37A (Tc) | 10V | 80mOhm @ 11.8A, 10V | 4V @ 590µA | 51 nC @ 10 V | ±20V | 2180 pF @ 400 V | - | 129W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-TO263-3 |
|
IPP60R080P7XKSA1MOSFET N-CH 650V 37A TO220-3 |
237 |
|
Datasheet |
CoolMOS™ P7 | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 37A (Tc) | 10V | 80mOhm @ 11.8A, 10V | 4V @ 590µA | 51 nC @ 10 V | ±20V | 2180 pF @ 400 V | - | 129W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | PG-TO220-3 |
|
|
FCP125N65S3MOSFET N-CH 650V 24A TO220-3 |
2,265 |
|
Datasheet |
SuperFET® III | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 24A (Tc) | 10V | 125mOhm @ 12A, 10V | 4.5V @ 2.4mA | 46 nC @ 10 V | ±30V | 1940 pF @ 400 V | - | 181W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220-3 |
|
|
FCP190N65FMOSFET N-CH 650V 20.6A TO220-3 |
2,134 |
|
Datasheet |
FRFET®, SuperFET® II | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 20.6A (Tc) | 10V | 190mOhm @ 10A, 10V | 5V @ 2mA | 78 nC @ 10 V | ±20V | 3225 pF @ 25 V | - | 208W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220-3 |
|
FDBL86363-F085MOSFET N-CH 80V 240A 8HPSOF |
1,849 |
|
Datasheet |
PowerTrench® | 8-PowerSFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 240A (Tc) | 10V | 2mOhm @ 80A, 10V | 4V @ 250µA | 169 nC @ 10 V | ±20V | 10000 pF @ 40 V | - | 357W (Tj) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 8-HPSOF |
|
SIHG105N60EF-GE3MOSFET N-CH 600V 29A TO247AC |
367 |
|
Datasheet |
EF | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 29A (Tc) | 10V | 102mOhm @ 13A, 10V | 5V @ 250µA | 53 nC @ 10 V | ±30V | 1804 pF @ 100 V | - | 208W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AC |
|
TK110U65Z,RQDTMOS VI TOLL PD=190W F=1MHZ |
5,960 |
|
Datasheet |
DTMOSVI | 8-PowerSFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 24A (Ta) | 10V | 110mOhm @ 12A, 10V | 4V @ 1.02mA | 40 nC @ 10 V | ±30V | 2250 pF @ 300 V | - | 190W (Tc) | 150°C | - | - | Surface Mount | TOLL |
|
TKR74F04PB,LXGQMOSFET N-CH 40V 250A TO220SM |
4,284 |
|
Datasheet |
U-MOSIX-H | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 250A (Ta) | 6V, 10V | 0.74mOhm @ 125A, 10V | 3V @ 1mA | 227 nC @ 10 V | ±20V | 14200 pF @ 10 V | - | 375W (Tc) | 175°C | - | - | Surface Mount | TO-220SM(W) |
|
SIHF080N60E-GE3E SERIES POWER MOSFET TO-220 FUL |
1,465 |
|
Datasheet |
E | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 14A (Tc) | 10V | 80mOhm @ 17A, 10V | 5V @ 250µA | 63 nC @ 10 V | ±30V | 2557 pF @ 100 V | - | 35W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 Full Pack |
|
STP20NM50MOSFET N-CH 500V 20A TO220AB |
774 |
|
Datasheet |
MDmesh™ | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 20A (Tc) | 10V | 250mOhm @ 10A, 10V | 5V @ 250µA | 56 nC @ 10 V | ±30V | 1480 pF @ 25 V | - | 192W (Tc) | -65°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 |
|
IRFBC40LCPBFMOSFET N-CH 600V 6.2A TO220AB |
1,006 |
|
Datasheet |
- | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 6.2A (Tc) | 10V | 1.2Ohm @ 3.7A, 10V | 4V @ 250µA | 39 nC @ 10 V | ±30V | 1100 pF @ 25 V | - | 125W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220AB |
|
|
STP10NK80ZMOSFET N-CH 800V 9A TO220AB |
958 |
|
Datasheet |
SuperMESH™ | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 9A (Tc) | 10V | 900mOhm @ 4.5A, 10V | 4.5V @ 100µA | 72 nC @ 10 V | ±30V | 2180 pF @ 25 V | - | 190W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 |
|
SIHP080N60E-GE3E SERIES POWER MOSFET TO-220AB, |
716 |
|
Datasheet |
E | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 35A (Tc) | 10V | 80mOhm @ 17A, 10V | 5V @ 250µA | 63 nC @ 10 V | ±30V | 2557 pF @ 100 V | - | 227W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220AB |
|
STB11NM60T4MOSFET N-CH 650V 11A D2PAK |
1,512 |
|
Datasheet |
MDmesh™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 650 V | 11A (Tc) | 10V | 450mOhm @ 5.5A, 10V | 5V @ 250µA | 30 nC @ 10 V | ±30V | 1000 pF @ 25 V | - | 160W (Tc) | -65°C ~ 150°C (TJ) | - | - | Surface Mount | D2PAK |
|
STF11NM60NDMOSFET N-CH 600V 10A TO220FP |
966 |
|
Datasheet |
FDmesh™ II | TO-220-3 Full Pack | Tube | Last Time Buy | N-Channel | MOSFET (Metal Oxide) | 600 V | 10A (Tc) | 10V | 450mOhm @ 5A, 10V | 5V @ 250µA | 30 nC @ 10 V | ±25V | 850 pF @ 50 V | - | 25W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220FP |
|
|
STH10N80K5-2AGMOSFET N-CH 800V 8A H2PAK-2 |
831 |
|
Datasheet |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 8A (Tc) | 10V | 680mOhm @ 4A, 10V | 5V @ 100µA | 17.3 nC @ 10 V | ±30V | 426 pF @ 100 V | - | 121W (Tc) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | H2Pak-2 |
|
|
FCP125N65S3R0MOSFET N-CH 650V 24A TO220-3 |
800 |
|
Datasheet |
SuperFET® III | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 24A (Tc) | 10V | 125mOhm @ 12A, 10V | 4.5V @ 2.4mA | 46 nC @ 10 V | ±30V | 1940 pF @ 400 V | - | 181W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220-3 |
|
NTB190N65S3HFMOSFET N-CH 650V 20A D2PAK-3 |
2,398 |
|
Datasheet |
FRFET®, SuperFET® III | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 20A (Tc) | 10V | 190mOhm @ 10A, 10V | 5V @ 430µA | 34 nC @ 10 V | ±30V | 1610 pF @ 400 V | - | 162W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
