Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Material - Core | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Supplier Device Package | Shielding | DC Resistance (DCR) | Inductance | Q @ Freq | Frequency - Self Resonant | Mounting Style | Ratings | Size / Dimension | Features | Operating Temperature | Inductance Frequency - Test | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CD75T125NP-820KCFIXED IND 82UH 1.34A 370MOHM SMD Sumida America Components Inc. |
2,504 |
|
Datasheet |
CD75/T125 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±10% | 1.34 A | 950mA | - | Unshielded | 370mOhm Max | 82 µH | - | - | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 2.52 MHz | 0.217" (5.50mm) |
|
|
CD75T125NP-100KCFIXED IND 10UH 3.18A 70 MOHM SMD Sumida America Components Inc. |
4,212 |
|
Datasheet |
CD75/T125 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±10% | 3.18 A | 2.8A | - | Unshielded | 70mOhm Max | 10 µH | - | - | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 2.52 MHz | 0.217" (5.50mm) |
|
|
CD75T125NP-121KCFIXED IND 120UH 1.17A 470MOHM SM Sumida America Components Inc. |
2,545 |
|
Datasheet |
CD75/T125 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±10% | 1.17 A | 870mA | - | Unshielded | 470mOhm Max | 120 µH | - | - | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 1 kHz | 0.217" (5.50mm) |
|
|
CD75T125NP-150KCFIXED IND 15UH 3.02A 90 MOHM SMD Sumida America Components Inc. |
4,092 |
|
Datasheet |
CD75/T125 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±10% | 3.02 A | 2.16A | - | Unshielded | 90mOhm Max | 15 µH | - | - | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 2.52 MHz | 0.217" (5.50mm) |
|
|
CD75T125NP-120KCFIXED IND 12UH 3.15A 80 MOHM SMD Sumida America Components Inc. |
4,824 |
|
Datasheet |
CD75/T125 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±10% | 3.15 A | 2.45A | - | Unshielded | 80mOhm Max | 12 µH | - | - | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 2.52 MHz | 0.217" (5.50mm) |
|
|
CD75T125NP-101KCFIXED IND 100UH 1.29A 430MOHM SM Sumida America Components Inc. |
3,841 |
|
Datasheet |
CD75/T125 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±10% | 1.29 A | 900mA | - | Unshielded | 430mOhm Max | 100 µH | - | - | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 1 kHz | 0.217" (5.50mm) |
|
|
CD75T125NP-330KCFIXED IND 33UH 2.35A 130MOHM SMD Sumida America Components Inc. |
2,732 |
|
Datasheet |
CD75/T125 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±10% | 2.35 A | 1.51A | - | Unshielded | 130mOhm Max | 33 µH | - | - | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 2.52 MHz | 0.217" (5.50mm) |
|
|
CD75T125NP-470KCFIXED IND 47UH 1.95A 180MOHM SMD Sumida America Components Inc. |
3,141 |
|
Datasheet |
CD75/T125 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±10% | 1.95 A | 1.26A | - | Unshielded | 180mOhm Max | 47 µH | - | - | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 2.52 MHz | 0.217" (5.50mm) |
|
CDRH3D14/HPNP-150NCFIXED IND 15UH 500MA 650MOHM SMD Sumida America Components Inc. |
2,050 |
|
Datasheet |
CDRH3D14/HP | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±25% | 500 mA | 800mA | - | Shielded | 650mOhm Max | 15 µH | - | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | - | -40°C ~ 105°C | 100 kHz | 0.059" (1.50mm) |
|
CDRH3D14/LDNP-1R2NCFIXED IND 1.2UH 2.7A 38 MOHM SMD Sumida America Components Inc. |
2,000 |
|
Datasheet |
CDRH3D14/LD | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±25% | 2.7 A | 1.5A | - | Shielded | 38mOhm Max | 1.2 µH | - | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | - | -40°C ~ 105°C | 100 kHz | 0.059" (1.50mm) |
