Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Material - Core | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Supplier Device Package | Shielding | DC Resistance (DCR) | Inductance | Q @ Freq | Frequency - Self Resonant | Mounting Style | Ratings | Size / Dimension | Features | Operating Temperature | Inductance Frequency - Test | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CDH53-330KCFIXED IND 33UH 670MA 490MOHM SMD Sumida America Components Inc. |
2,322 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±10% | 670 mA | - | - | Unshielded | 490mOhm Max | 33 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -40°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
|
CDH53-390KCFIXED IND 39UH 640MA 550MOHM SMD Sumida America Components Inc. |
3,955 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±10% | 640 mA | - | - | Unshielded | 550mOhm Max | 39 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -30°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
|
|
CDH53-470KCFIXED IND 47UH 530MA 770MOHM SMD Sumida America Components Inc. |
4,807 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±10% | 530 mA | - | - | Unshielded | 770mOhm Max | 47 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -30°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
|
|
CDH53-560KCFIXED IND 56UH 500MA 870MOHM SMD Sumida America Components Inc. |
4,168 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±10% | 500 mA | - | - | Unshielded | 870mOhm Max | 56 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -30°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
|
|
CDH53-680JCFIXED IND 68UH 450MA 1.21OHM SMD Sumida America Components Inc. |
4,420 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±5% | 450 mA | - | - | Unshielded | 1.21Ohm Max | 68 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -30°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
|
|
CDH53-820JCFIXED IND 82UH 390MA 1.34OHM SMD Sumida America Components Inc. |
4,595 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±5% | 390 mA | - | - | Unshielded | 1.34Ohm Max | 82 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -30°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
|
|
CDH53-101JCFIXED IND 100UH 370MA 1.57OHM SM Sumida America Components Inc. |
4,717 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±5% | 370 mA | - | - | Unshielded | 1.57Ohm Max | 100 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -40°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
|
|
CDH53-121JCFIXED IND 120UH 340MA 1.8OHM SMD Sumida America Components Inc. |
4,796 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±5% | 340 mA | - | - | Unshielded | 1.8Ohm Max | 120 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -30°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
|
|
CDH53-151JCFIXED IND 150UH 310MA 2.4MOHM SM Sumida America Components Inc. |
4,830 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±5% | 310 mA | - | - | Unshielded | 2.4mOhm Max | 150 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -30°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
|
|
CDH53-181JCFIXED IND 180UH 300MA 2.66OHM SM Sumida America Components Inc. |
4,760 |
|
Datasheet |
CDH53 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±5% | 300 mA | - | - | Unshielded | 2.66Ohm Max | 180 µH | - | - | Surface Mount | - | 0.236" L x 0.205" W (6.00mm x 5.20mm) | - | -30°C ~ 100°C | 1 kHz | 0.126" (3.20mm) |
