Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Material - Core | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Supplier Device Package | Shielding | DC Resistance (DCR) | Inductance | Q @ Freq | Frequency - Self Resonant | Mounting Style | Ratings | Size / Dimension | Features | Operating Temperature | Inductance Frequency - Test | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
744765175GAFIXED IND 75NH 160MA 1.2 OHM SMD Würth Elektronik |
3,764 |
|
Datasheet |
WE-KI | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 160 mA | - | 0402 | Unshielded | 1.2Ohm Max | 75 nH | 20 @ 200MHz | 1.55GHz | Surface Mount | AEC-Q200 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | - | -40°C ~ 125°C | 200 MHz | 0.024" (0.60mm) |
|
|
744765124GAFIXED IND 24NH 400MA 300MOHM SMD Würth Elektronik |
3,299 |
|
Datasheet |
WE-KI | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 400 mA | - | 0402 | Unshielded | 300mOhm Max | 24 nH | 25 @ 250MHz | 2.7GHz | Surface Mount | AEC-Q200 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | - | -40°C ~ 125°C | 250 MHz | 0.024" (0.60mm) |
|
|
744765120GAFIXED IND 20NH 420MA 250MOHM SMD Würth Elektronik |
3,204 |
|
Datasheet |
WE-KI | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 420 mA | - | 0402 | Unshielded | 250mOhm Max | 20 nH | 25 @ 250MHz | 3GHz | Surface Mount | AEC-Q200 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | - | -40°C ~ 125°C | 250 MHz | 0.024" (0.60mm) |
|
|
744765151GAFIXED IND 51NH 100MA 820MOHM SMD Würth Elektronik |
4,123 |
|
Datasheet |
WE-KI | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 100 mA | - | 0402 | Unshielded | 820mOhm Max | 51 nH | 25 @ 200MHz | 1.75GHz | Surface Mount | AEC-Q200 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | - | -40°C ~ 125°C | 200 MHz | 0.024" (0.60mm) |
|
|
744765116GAFIXED IND 16NH 460MA 220MOHM SMD Würth Elektronik |
3,000 |
|
Datasheet |
WE-KI | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 460 mA | - | 0402 | Unshielded | 220mOhm Max | 16 nH | 24 @ 250MHz | 3.1GHz | Surface Mount | AEC-Q200 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | - | -40°C ~ 125°C | 250 MHz | 0.024" (0.60mm) |
|
744762118GAFIXED IND 18NH 1A 100 MOHM SMD Würth Elektronik |
3,635 |
|
Datasheet |
WE-KI | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 1 A | - | 1008 | Unshielded | 100mOhm Max | 18 nH | 60 @ 350MHz | 2.7GHz | Surface Mount | AEC-Q200 | 0.098" L x 0.079" W (2.50mm x 2.00mm) | - | -40°C ~ 125°C | 100 MHz | 0.071" (1.80mm) |
|
|
744765143GAFIXED IND 43NH 100MA 810MOHM SMD Würth Elektronik |
4,176 |
|
Datasheet |
WE-KI | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 100 mA | - | 0402 | Unshielded | 810mOhm Max | 43 nH | 25 @ 250MHz | 2.03GHz | Surface Mount | AEC-Q200 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | - | -40°C ~ 125°C | 250 MHz | 0.024" (0.60mm) |
|
|
744765113GAFIXED IND 13NH 560MA 210MOHM SMD Würth Elektronik |
4,971 |
|
Datasheet |
WE-KI | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 560 mA | - | 0402 | Unshielded | 210mOhm Max | 13 nH | 24 @ 250MHz | 3.45GHz | Surface Mount | AEC-Q200 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | - | -40°C ~ 125°C | 250 MHz | 0.024" (0.60mm) |
|
|
744765127GAFIXED IND 27NH 400MA 298MOHM SMD Würth Elektronik |
4,328 |
|
Datasheet |
WE-KI | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 400 mA | - | 0402 | Unshielded | 298mOhm Max | 27 nH | 26 @ 250MHz | 2.48GHz | Surface Mount | AEC-Q200 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | - | -40°C ~ 125°C | 250 MHz | 0.024" (0.60mm) |
|
|
744765123GAFIXED IND 23NH 400MA 214MOHM SMD Würth Elektronik |
4,725 |
|
Datasheet |
WE-KI | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | ±2% | 400 mA | - | 0402 | Unshielded | 214mOhm Max | 23 nH | 26 @ 250MHz | 2.72GHz | Surface Mount | AEC-Q200 | 0.039" L x 0.022" W (1.00mm x 0.55mm) | - | -40°C ~ 125°C | 250 MHz | 0.024" (0.60mm) |
