Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Material - Core | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Supplier Device Package | Shielding | DC Resistance (DCR) | Inductance | Q @ Freq | Frequency - Self Resonant | Mounting Style | Ratings | Size / Dimension | Features | Operating Temperature | Inductance Frequency - Test | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRU1038A-331YFIXED IND 330UH 550MA 1 OHM SMD Bourns Inc. |
4,213 |
|
Datasheet |
SRU1038A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 550 mA | 520mA | - | Shielded | 1Ohm Max | 330 µH | 20 @ 796kHz | 3MHz | Surface Mount | AEC-Q200 | 0.394" L x 0.394" W (10.00mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.161" (4.10mm) |
|
SRR6040A-560MFIXED IND 56UH 860MA 190MOHM SMD Bourns Inc. |
3,037 |
|
Datasheet |
SRR6040A | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | - | Ferrite | ±20% | 860 mA | 770mA | - | Shielded | 190mOhm Max | 56 µH | - | - | Surface Mount | AEC-Q200 | 0.264" L x 0.264" W (6.70mm x 6.70mm) | - | -40°C ~ 125°C | 10 kHz | 0.157" (4.00mm) |
|
|
SRR6040A-6R8YFIXED IND 6.8UH 2.5A 30 MOHM SMD Bourns Inc. |
3,548 |
|
Datasheet |
SRR6040A | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | - | Ferrite | ±30% | 2.5 A | 2.17A | - | Shielded | 30mOhm Max | 6.8 µH | - | - | Surface Mount | AEC-Q200 | 0.264" L x 0.264" W (6.70mm x 6.70mm) | - | -40°C ~ 125°C | 10 kHz | 0.157" (4.00mm) |
|
SRP0612-4R7KFIXED IND 4.7UH 3.9A 82 MOHM SMD Bourns Inc. |
2,607 |
|
Datasheet |
SRP0612 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Metal | ±10% | 3.9 A | 5A | - | Shielded | 82mOhm Max | 4.7 µH | 32 @ 7.96MHz | 15MHz | Surface Mount | - | 0.280" L x 0.264" W (7.10mm x 6.70mm) | - | -40°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
|
SRP0615-6R8KFIXED IND 6.8UH 3.6A 87 MOHM SMD Bourns Inc. |
3,542 |
|
Datasheet |
SRP0615 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Metal | ±10% | 3.6 A | 5.2A | - | Shielded | 87mOhm Max | 6.8 µH | 31 @ 7.96MHz | 14MHz | Surface Mount | - | 0.280" L x 0.264" W (7.10mm x 6.70mm) | - | -40°C ~ 125°C | 100 kHz | 0.059" (1.50mm) |
|
|
SRP0612-R68KFIXED IND 680NH 7A 22.3 MOHM SMD Bourns Inc. |
4,886 |
|
Datasheet |
SRP0612 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Metal | ±10% | 7 A | 15A | - | Shielded | 22.3mOhm Max | 680 nH | 21 @ 25.2MHz | 55MHz | Surface Mount | - | 0.280" L x 0.264" W (7.10mm x 6.70mm) | - | -40°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
|
|
SRP0612-6R8KFIXED IND 6.8UH 3A 125 MOHM SMD Bourns Inc. |
2,802 |
|
Datasheet |
SRP0612 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Metal | ±10% | 3 A | 4A | - | Shielded | 125mOhm Max | 6.8 µH | 29 @ 7.96MHz | 14MHz | Surface Mount | - | 0.280" L x 0.264" W (7.10mm x 6.70mm) | - | -40°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
|
|
SRP0612-1R5KFIXED IND 1.5UH 6A 32.8 MOHM SMD Bourns Inc. |
3,355 |
|
Datasheet |
SRP0612 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Metal | ±10% | 6 A | 9A | - | Shielded | 32.8mOhm Max | 1.5 µH | 42 @ 7.96MHz | 22MHz | Surface Mount | - | 0.280" L x 0.264" W (7.10mm x 6.70mm) | - | -40°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
|
|
SRP0612-2R2KFIXED IND 2.2UH 5.5A 38.8MOHM SM Bourns Inc. |
3,367 |
|
Datasheet |
SRP0612 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Metal | ±10% | 5.5 A | 7A | - | Shielded | 38.8mOhm Max | 2.2 µH | 22 @ 7.96MHz | 32MHz | Surface Mount | - | 0.280" L x 0.264" W (7.10mm x 6.70mm) | - | -40°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
|
SRP0620-R47KFIXED IND 470NH 15.5A 5.5MOHM SM Bourns Inc. |
4,770 |
|
Datasheet |
SRP0620 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Metal | ±10% | 15.5 A | 25A | - | Shielded | 5.5mOhm Max | 470 nH | 19 @ 25.2MHz | 63MHz | Surface Mount | - | 0.280" L x 0.264" W (7.10mm x 6.70mm) | - | -40°C ~ 125°C | 100 kHz | 0.079" (2.00mm) |
