Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XGL3515-122MECFIXED INDUCTOR 1.2UH SMD Coilcraft |
2,294 |
|
Datasheet |
XGL3515 | Nonstandard | Strip | Active | Molded | Metal Composite | 1.2 µH | ±20% | 6.8 A | 4.3A | Shielded | 27.2mOhm Max | - | 70MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.059" (1.50mm) |
|
|
XGL3515-221MECFIXED INDUCTOR 0.22UH SMD Coilcraft |
1,161 |
|
Datasheet |
XGL3515 | Nonstandard | Strip | Active | Molded | Metal Composite | 220 nH | ±20% | 16.1 A | 11.1A | Shielded | 5.6mOhm Max | - | 200MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.059" (1.50mm) |
|
|
XGL3515-102MECFIXED INDUCTOR 1UH SMD Coilcraft |
268 |
|
Datasheet |
XGL3515 | Nonstandard | Strip | Active | Molded | Metal Composite | 1 µH | ±20% | 7.9 A | 4.9A | Shielded | 21.3mOhm Max | - | 72MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.059" (1.50mm) |
|
MSS1038-103NLCFIXED IND 10UH 4.05A 35MOHM SM Coilcraft |
48,681 |
|
Datasheet |
MSS1038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 10 µH | ±30% | 4.05 A | 3.04A | Shielded | 35mOhm Max | - | 29MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.157" (4.00mm) |
|
|
MSS1038-333MLCFIXED IND 33UH 2.3A 93MOHM SM Coilcraft |
18,331 |
|
Datasheet |
MSS1038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 33 µH | ±20% | 2.3 A | 1.84A | Shielded | 93mOhm Max | - | 13MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.157" (4.00mm) |
|
|
MSS1038-102NLCFIXED IND 1UH 10A 6MOHM SM Coilcraft |
16,950 |
|
Datasheet |
MSS1038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 1 µH | ±30% | 10 A | 9A | Shielded | 6mOhm Max | - | 138MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.157" (4.00mm) |
|
|
MSS1038-683MLCFIXED IND 68UH 1.75A 213MOHM SM Coilcraft |
13,006 |
|
Datasheet |
MSS1038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 68 µH | ±20% | 1.75 A | 1.32A | Shielded | 213mOhm Max | - | 10MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.157" (4.00mm) |
|
|
MSS1038-223MLCFIXED IND 22UH 2.85A 73MOHM SM Coilcraft |
12,851 |
|
Datasheet |
MSS1038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 22 µH | ±20% | 2.85 A | 2.34A | Shielded | 73mOhm Max | - | 15MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.157" (4.00mm) |
|
|
MSS1038-823MLCFIXED IND 82UH 1.5A 261MOHM SM Coilcraft |
12,064 |
|
Datasheet |
MSS1038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 82 µH | ±20% | 1.5 A | 1.12A | Shielded | 261mOhm Max | - | 8MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.157" (4.00mm) |
|
|
MSS1038-152NLCFIXED IND 1.5UH 7.85A 8.1MOHM SM Coilcraft |
10,376 |
|
Datasheet |
MSS1038 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 1.5 µH | ±30% | 7.85 A | 7.4A | Shielded | 8.1mOhm Max | - | 81MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.157" (4.00mm) |
