Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ELJ-FB331KFFIXED IND 330UH 75MA 16 OHM SMD |
3,371 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 330 µH | ±10% | 75 mA | - | Unshielded | 16Ohm Max | 40 @ 796kHz | 3.7MHz | - | -20°C ~ 85°C | 100 kHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB390KFFIXED IND 39UH 165MA 3.6 OHM SMD |
4,175 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 39 µH | ±10% | 165 mA | - | Unshielded | 3.6Ohm Max | 50 @ 2.52MHz | 10MHz | - | -20°C ~ 85°C | 1 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB391KFFIXED IND 390UH 70MA 19 OHM SMD |
2,763 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 390 µH | ±10% | 70 mA | - | Unshielded | 19Ohm Max | 40 @ 796kHz | 3.3MHz | - | -20°C ~ 85°C | 100 kHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB3R3MFFIXED IND 3.3UH 380MA 660MOHM SM |
2,288 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 3.3 µH | ±20% | 380 mA | - | Unshielded | 660mOhm Max | 50 @ 7.96MHz | 39MHz | - | -20°C ~ 85°C | 1 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB3R9MFFIXED IND 3.9UH 360MA 740MOHM SM |
4,156 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 3.9 µH | ±20% | 360 mA | - | Unshielded | 740mOhm Max | 50 @ 7.96MHz | 36MHz | - | -20°C ~ 85°C | 1 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB470KFFIXED IND 47UH 130MA 4.2 OHM SMD |
2,910 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 47 µH | ±10% | 130 mA | - | Unshielded | 4.2Ohm Max | 50 @ 2.52MHz | 9.7MHz | - | -20°C ~ 85°C | 1 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB471KFFIXED IND 470UH 55MA 31 OHM SMD |
3,086 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 470 µH | ±10% | 55 mA | - | Unshielded | 31Ohm Max | 30 @ 796kHz | 3.3MHz | - | -20°C ~ 85°C | 100 kHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB4R7MFFIXED IND 4.7UH 350MA 810MOHM SM |
4,698 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 4.7 µH | ±20% | 350 mA | - | Unshielded | 810mOhm Max | 50 @ 5MHz | 33MHz | - | -20°C ~ 85°C | 1 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB560KFFIXED IND 56UH 125MA 4.7 OHM SMD |
3,231 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 56 µH | ±10% | 125 mA | - | Unshielded | 4.7Ohm Max | 40 @ 2.52MHz | 9MHz | - | -20°C ~ 85°C | 100 kHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB561KFFIXED IND 560UH 50MA 35 OHM SMD |
3,062 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 560 µH | ±10% | 50 mA | - | Unshielded | 35Ohm Max | 30 @ 796kHz | 2.7MHz | - | -20°C ~ 85°C | 100 kHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB5R6MFFIXED IND 5.6UH 330MA 880MOHM SM |
3,616 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 5.6 µH | ±20% | 330 mA | - | Unshielded | 880mOhm Max | 50 @ 5MHz | 30MHz | - | -20°C ~ 85°C | 1 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB680KFFIXED IND 68UH 115MA 5.3 OHM SMD |
3,893 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 68 µH | ±10% | 115 mA | - | Unshielded | 5.3Ohm Max | 40 @ 2.52MHz | 8.2MHz | - | -20°C ~ 85°C | 100 kHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB681KFFIXED IND 680UH 50MA 39 OHM SMD |
3,618 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 680 µH | ±10% | 50 mA | - | Unshielded | 39Ohm Max | 30 @ 796kHz | 2.5MHz | - | -20°C ~ 85°C | 100 kHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB6R8MFFIXED IND 6.8UH 310MA 1 OHM SMD |
4,409 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 6.8 µH | ±20% | 310 mA | - | Unshielded | 1Ohm Max | 50 @ 5MHz | 26MHz | - | -20°C ~ 85°C | 1 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB820KFFIXED IND 82UH 110MA 5.9 OHM SMD |
3,192 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 82 µH | ±10% | 110 mA | - | Unshielded | 5.9Ohm Max | 40 @ 2.52MHz | 7.5MHz | - | -20°C ~ 85°C | 100 kHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB821KFFIXED IND 820UH 45MA 45 OHM SMD |
3,736 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 820 µH | ±10% | 45 mA | - | Unshielded | 45Ohm Max | 30 @ 796kHz | 2.4MHz | - | -20°C ~ 85°C | 100 kHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
ELJ-FB8R2MFFIXED IND 8.2UH 250MA 1.6OHM SMD |
4,101 |
|
Datasheet |
FB | 1812 (4532 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 8.2 µH | ±20% | 250 mA | - | Unshielded | 1.6Ohm Max | 50 @ 5MHz | 24MHz | - | -20°C ~ 85°C | 1 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
ELJ-FC101KFFIXED IND 100UH 60MA 21 OHM SMD |
4,296 |
|
Datasheet |
FC | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 100 µH | ±10% | 60 mA | - | Unshielded | 21Ohm Max | 15 @ 796kHz | 12MHz | - | -20°C ~ 85°C | 796 kHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
ELJ-FC2R2MFFIXED IND 2.2UH 155MA 1.05OHM SM |
4,179 |
|
Datasheet |
FC | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 2.2 µH | ±20% | 155 mA | - | Unshielded | 1.05Ohm Max | 25 @ 7.96MHz | 80MHz | - | -20°C ~ 85°C | 7.96 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
ELJ-FC330KFFIXED IND 33UH 110MA 7.1 OHM SMD |
3,004 |
|
Datasheet |
FC | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 33 µH | ±10% | 110 mA | - | Unshielded | 7.1Ohm Max | 20 @ 2.52MHz | 20MHz | - | -20°C ~ 85°C | 2.52 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
