Isolators - Gate Drivers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Technology | Number of Channels | Common Mode Transient Immunity (Min) | Propagation Delay tpLH / tpHL (Max) | Pulse Width Distortion (Max) | Mounting Style | Rise / Fall Time (Typ) | Current - Output High, Low | Voltage - Isolation | Current - Peak Output | Voltage - Forward (Vf) (Typ) | Operating Temperature | Current - DC Forward (If) (Max) | Supplier Device Package | Qualification | Voltage - Output Supply | Grade | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SI8235AD-ASDGTL ISO 5KV 2CH GATE DVR 16SOIC |
2,097 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | 2 | 20kV/µs | 45ns, 45ns | 5.6ns | Surface Mount | 12ns, 12ns (Max) | 2A, 4A | 5000Vrms | 4A | - | -40°C ~ 125°C | - | 16-SOIC | AEC-Q100 | 6.5V ~ 24V | Automotive | CQC, CSA, UL, VDE |
|
SI8281BC-ISDGTL ISO 5KV 1CH GATE DVR 20SOIC |
2,029 |
|
Datasheet |
- | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | 1 | 35kV/µs | 50ns, 50ns | 5ns | Surface Mount | 5.5ns, 8.5ns | 2.5A, 3A | 5000Vrms | 4A | - | -40°C ~ 125°C | - | 20-SOIC | AEC-Q100 | 2.8V ~ 5.5V | Automotive | CQC, CSA, UL, VDE |
|
|
SI8282CC-ISDGTL ISO 5KV 1CH GATE DVR 20SOIC |
4,852 |
|
Datasheet |
- | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | 1 | 35kV/µs | 50ns, 50ns | 5ns | Surface Mount | 5.5ns, 8.5ns | 2.5A, 3A | 5000Vrms | 4A | - | -40°C ~ 125°C | - | 20-SOIC | AEC-Q100 | 2.8V ~ 5.5V | Automotive | CQC, CSA, UL, VDE |
|
|
SI8281EC-ISDGTL ISO 5KV 1CH GATE DVR 20SOIC |
4,173 |
|
Datasheet |
- | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | 1 | 125kV/µs | 50ns, 50ns | 5ns | Surface Mount | 5.5ns, 8.5ns | 2A, 4.1A | 5000Vrms | 4A | - | -40°C ~ 125°C | - | 20-SOIC | AEC-Q100 | 16V ~ 30V | Automotive | CQC, CSA, UL, VDE |
|
|
SI8281DC-ISDGTL ISO 5KV 1CH GATE DVR 20SOIC |
4,306 |
|
Datasheet |
- | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | 1 | 125kV/µs | 50ns, 50ns | 5ns | Surface Mount | 5.5ns, 8.5ns | 2A, 4.1A | 5000Vrms | 4A | - | -40°C ~ 125°C | - | 20-SOIC | AEC-Q100 | 14V ~ 30V | Automotive | CQC, CSA, UL, VDE |
|
|
SI8282DC-ISDGTL ISO 5KV 1CH GATE DVR 20SOIC |
4,013 |
|
Datasheet |
- | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | 1 | 125kV/µs | 50ns, 50ns | 5ns | Surface Mount | 5.5ns, 8.5ns | 2A, 4.1A | 5000Vrms | 4A | - | -40°C ~ 125°C | - | 20-SOIC | AEC-Q100 | 14V ~ 30V | Automotive | CQC, CSA, UL, VDE |
|
|
SI8282EC-ISDGTL ISO 5KV 1CH GATE DVR 20SOIC |
2,145 |
|
Datasheet |
- | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | 1 | 125kV/µs | 50ns, 50ns | 5ns | Surface Mount | 5.5ns, 8.5ns | 2A, 4.1A | 5000Vrms | 4A | - | -40°C ~ 125°C | - | 20-SOIC | AEC-Q100 | 16V ~ 30V | Automotive | CQC, CSA, UL, VDE |
|
|
SI8233AB-AS1RDGTL ISO 2.5KV 2CH GT DVR 16SOIC |
2,689 |
|
- |
- | 16-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | Capacitive Coupling | 2 | 20kV/µs | 45ns, 45ns | 5.6ns | Surface Mount | 12ns, 12ns (Max) | 2A, 4A | 2500Vrms | 4A | - | -40°C ~ 125°C | - | 16-SOIC | AEC-Q100 | 6.5V ~ 24V | Automotive | CQC, CSA, UL, VDE |
|
|
SI8274DB1-AS1RDGTL ISO 2.5KV 2CH GT DVR 16SOIC |
2,008 |
|
- |
SI827x | 16-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | RF Coupling | 2 | 200kV/µs | 105ns, 75ns | 47ns | Surface Mount | 10.5ns, 13.3ns | 1.8A, 4A | 2500Vrms | 4A | - | -40°C ~ 125°C | - | 16-SOIC | AEC-Q100 | 4.2V ~ 30V | Automotive | CQC, CSA, UL, VDE |
|
|
SI8282DC-ASDGTL ISO 5KV 1CH GATE DVR 20SOIC |
2,975 |
|
- |
- | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | 1 | 125kV/µs | 50ns, 50ns | 5ns | Surface Mount | 5.5ns, 8.5ns | 2A, 4.1A | 5000Vrms | 4A | - | -40°C ~ 125°C | - | 20-SOIC | AEC-Q100 | 14V ~ 30V | Automotive | CQC, CSA, UL, VDE |
|
|
SI8281CC-ASDGTL ISO 5KV 1CH GATE DVR 20SOIC |
3,852 |
|
- |
- | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | 1 | 125kV/µs | 50ns, 50ns | 5ns | Surface Mount | 5.5ns, 8.5ns | 2A, 4.1A | 5000Vrms | 4A | - | -40°C ~ 125°C | - | 20-SOIC | AEC-Q100 | 13.2V ~ 30V | Automotive | CQC, CSA, UL, VDE |
|
ACPL-350J-000EOPTOISO 5KV 1CH GATE DVR 16SOIC |
2,331 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Last Time Buy | Optical Coupling | 1 | 100kV/µs | 150ns, 150ns | 50ns | Surface Mount | 37ns, 30ns | 2.5A, 2.5A | 5000Vrms | 3A | 1.55V | -40°C ~ 105°C | 25 mA | 16-SOIC | - | 15V ~ 30V | - | CSA, UL, VDE |
|
BM6104FV-CE2DGTL ISO 2.5KV 1CH GT DVR 20SSOP |
4,105 |
|
Datasheet |
- | 20-SSOP (0.240", 6.10mm Width) | Tape & Reel (TR) | Active | Magnetic Coupling | 1 | 100kV/µs | 150ns, 150ns | - | Surface Mount | 50ns, 50ns | - | 2500Vrms | 5A, 1A | - | -40°C ~ 125°C | - | 20-SSOP-BW | AEC-Q100 | 10V ~ 24V | Automotive | UR |
|
|
SC900631BEKISOLATED GATE DRIVERS HV ISOLATE |
2,526 |
|
- |
- | - | Tube | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SC900633BEKISOLATED GATE DRIVERS HV ISOLATE |
4,320 |
|
- |
- | - | Tube | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
MGD3160AM515EKSNGL CH GATE DRIVER 32SOIC |
3,018 |
|
Datasheet |
- | 32-BSSOP (0.295", 7.50mm Width) | Tube | Active | - | 1 | - | - | - | Surface Mount | - | 15A, 15A | - | 15A | - | -40°C ~ 125°C | - | 32-SOIC | - | 4.75V ~ 40V | - | - |
|
|
MGD3160AM315EKSNGL CH GATE DRIVER 32SOIC |
3,133 |
|
Datasheet |
- | 32-BSSOP (0.295", 7.50mm Width) | Tube | Obsolete | - | 1 | - | - | - | Surface Mount | - | 15A, 15A | - | 15A | - | -40°C ~ 125°C | - | 32-SOIC | - | 4.5V ~ 40V | - | - |
|
|
ACPL-350J-500EOPTOISO 5KV 1CH GATE DVR 16SOIC |
4,609 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Last Time Buy | Optical Coupling | 1 | 100kV/µs | 150ns, 150ns | 50ns | Surface Mount | 37ns, 30ns | 2.5A, 2.5A | 5000Vrms | 3A | 1.55V | -40°C ~ 105°C | 25 mA | 16-SOIC | - | 15V ~ 30V | - | CSA, UL, VDE |
|
|
SI823H5BB-AS1DGTL ISO 2.5KV 2CH GT DVR 16SOIC |
2,644 |
|
Datasheet |
- | 16-SOIC (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | 2 | 125kV/µs | 30ns, 30ns | 5ns | Surface Mount | 12ns, 12ns (Max) | 4A, 4A | 2500Vrms | 6A | - | -40°C ~ 125°C | - | 16-SOIC | AEC-Q100 | 5.5V ~ 30V | Automotive | CQC, CSA, UL, VDE |
|
|
SI823H3CB-AS1DGTL ISO 2.5KV 2CH GT DVR 16SOIC |
3,397 |
|
Datasheet |
- | 16-SOIC (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | 2 | 125kV/µs | 116ns, 116ns | 5ns | Surface Mount | 12ns, 12ns (Max) | 4A, 4A | 2500Vrms | 6A | - | -40°C ~ 125°C | - | 16-SOIC | AEC-Q100 | 5.5V ~ 30V | Automotive | CQC, CSA, UL, VDE |
