Logic Output Optoisolators
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Number of Channels | Inputs - Side 1/Side 2 | Voltage - Isolation | Common Mode Transient Immunity (Min) | Input Type | Output Type | Current - Output / Channel | Data Rate | Propagation Delay tpLH / tpHL (Max) | Rise / Fall Time (Typ) | Voltage - Forward (Vf) (Typ) | Current - DC Forward (If) (Max) | Voltage - Supply | Grade | Qualification | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TLP2270(LF4,EPHOTOCOUPLER; HI-SPEED; LOW INPU Toshiba Semiconductor and Storage |
63 |
|
Datasheet |
- | 8-SOIC (0.295", 7.50mm Width) | Tube | Active | 2 | 2/0 | 5000Vrms | 20kV/µs | AC, DC | Push-Pull, Totem Pole | 10 mA | 20MBd | 60ns, 60ns | 1.3ns, 1ns | 1.5V | 8mA | 2.7V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 8-SO |
|
TLP2767(EHIGH SPEED LOGIC OUTPUT OPTOCOUP Toshiba Semiconductor and Storage |
45 |
|
Datasheet |
- | 6-SOIC (0.295", 7.50mm Width) | Tube | Active | 1 | 1/0 | 5000Vrms | 25kV/µs | AC, DC | Push-Pull, Totem Pole | 10 mA | 50MBd | 20ns, 20ns | 2ns, 1ns | 2.1V (Max) | 15mA | 2.7V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 6-SO |
|
|
TLP5832(D4,EIGBT GATE DRIVE PHOTOCOUPLER; SO Toshiba Semiconductor and Storage |
75 |
|
Datasheet |
- | 8-SOIC (0.295", 7.50mm Width) | Tube | Active | 1 | 1/0 | 5000Vrms | 20kV/µs | DC | Push-Pull, Totem Pole | - | - | 200ns, 200ns | 15ns, 8ns | 1.55V | 20mA | 15V ~ 30V | - | - | -40°C ~ 110°C | Surface Mount | 8-SO |
|
|
TLP5832(EIGBT GATE DRIVE PHOTOCOUPLER; SO Toshiba Semiconductor and Storage |
75 |
|
Datasheet |
- | 8-SOIC (0.295", 7.50mm Width) | Tube | Active | 1 | 1/0 | 5000Vrms | 20kV/µs | DC | Push-Pull, Totem Pole | - | - | 200ns, 200ns | 15ns, 8ns | 1.55V | 20mA | 15V ~ 30V | - | - | -40°C ~ 110°C | Surface Mount | 8-SO |
|
|
TLP2270(D4-LF4,EPHOTOCOUPLER; HI-SPEED; LOW INPU Toshiba Semiconductor and Storage |
40 |
|
Datasheet |
- | 8-SOIC (0.295", 7.50mm Width) | Tube | Active | 2 | 2/0 | 5000Vrms | 20kV/µs | AC, DC | Push-Pull, Totem Pole | 10 mA | 20MBd | 60ns, 60ns | 1.3ns, 1ns | 1.5V | 8mA | 2.7V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 8-SO |
.JPG)
|
TLP116A(EOPTOISO 3.75KV PUSH PULL SO6-5 Toshiba Semiconductor and Storage |
51 |
|
Datasheet |
- | 6-SOIC (0.179", 4.55mm Width), 5 Leads | Tube | Last Time Buy | 1 | 1/0 | 3750Vrms | 10kV/µs | DC | Push-Pull, Totem Pole | 10 mA | 20MBd | 60ns, 60ns | 15ns, 15ns | 1.58V | 20mA | 4.5V ~ 5.5V | - | - | -40°C ~ 100°C | Surface Mount | 6-SO, 5 Lead |
|
TLP2748(TP,EOPTOISO 5KV PUSH PULL SO6L Toshiba Semiconductor and Storage |
4,566 |
|
Datasheet |
- | 6-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | 1 | 1/0 | 5000Vrms | 30kV/µs | DC | Push-Pull, Totem Pole | 50 mA | - | 120ns, 120ns | 3ns, 3ns | 1.55V | 15mA | 4.5V ~ 30V | - | - | -40°C ~ 110°C | Surface Mount | 6-SO |
|
|
TLP2761(D4-TP,EHIGH SPEED LOGIC OUTPUT OPTOCOUP Toshiba Semiconductor and Storage |
2,678 |
|
Datasheet |
- | 6-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | 1 | 1/0 | 5000Vrms | 20kV/µs | AC, DC | Push-Pull, Totem Pole | 10 mA | 15MBd | 80ns, 80ns | 3ns, 3ns | 1.5V | 10mA | 2.7V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 6-SO |
|
TLP250H(F)X36 PB-F DRIVER COUPLER DIP 8 TH Toshiba Semiconductor and Storage |
2,858 |
|
Datasheet |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | 1 | 1/0 | 3750Vrms | 40kV/µs | DC | Push-Pull, Totem Pole | 2.5 A | - | 500ns, 500ns | 50ns, 50ns | 1.57V | 20mA | 10V ~ 30V | - | - | -40°C ~ 125°C | Through Hole | 8-DIP |
|
TLP2662(F)OPTOISO 5KV 2CH OPN COL 8DIP Toshiba Semiconductor and Storage |
3 |
|
Datasheet |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | 2 | 2/0 | 5000Vrms | 20kV/µs | DC | Open Collector | 25 mA | 10MBd | 75ns, 75ns | 12ns, 3ns | 1.55V | 20mA | 2.7V ~ 5.5V | - | - | -40°C ~ 125°C | Through Hole | 8-DIP |
