Signal Relays, Up to 2 Amps
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Mounting Style | Coil Voltage | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Release Time | Coil Current | Coil Type | Contact Form | Features | Termination Style | Operate Time | Seal Rating | Operating Temperature | Must Release Voltage | Coil Insulation | Must Operate Voltage | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS2E-S-DC24VRELAY GEN PURPOSE DPDT 2A 24V |
4,416 |
|
Datasheet |
DS | Box | Obsolete | Through Hole | 24VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 8.3 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 2.4 VDC | - | 16.8 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC48VRELAY GEN PURPOSE DPDT 2A 48V |
3,391 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 48VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 4.2 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 4.8 VDC | - | 33.6 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
DS2E-SL2-DC5VRELAY GENERAL PURPOSE DPDT 2A 5V |
4,706 |
|
Datasheet |
DS | Bulk | Obsolete | Through Hole | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 36 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 3.5 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL2-DC12VRELAY GEN PURPOSE DPDT 2A 12V |
2,357 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 15 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 8.4 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL2-DC24VRELAY GEN PURPOSE DPDT 2A 24V |
4,667 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 24VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 7.5 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 16.8 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL2-DC48VRELAY GEN PURPOSE DPDT 2A 48V |
2,263 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 48VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 3.8 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 33.6 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-M-DC5VRELAY GENERAL PURPOSE DPDT 2A 5V |
4,318 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 80 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 0.5 VDC | - | 3.5 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-M-DC12VRELAY GEN PURPOSE DPDT 2A 12V |
3,797 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 33.3 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 1.2 VDC | - | 8.4 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-M-DC24VRELAY GEN PURPOSE DPDT 2A 24V |
4,031 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 24VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 16.7 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 2.4 VDC | - | 16.8 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-M-DC48VRELAY GEN PURPOSE DPDT 2A 48V |
3,766 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 48VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 8.3 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 4.8 VDC | - | 33.6 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-ML2-DC5VRELAY GENERAL PURPOSE DPDT 2A 5V |
4,736 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 72 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 3.5 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-ML2-DC12VRELAY GEN PURPOSE DPDT 2A 12V |
4,380 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 30 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 8.4 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-ML2-DC24VRELAY GEN PURPOSE DPDT 2A 24V |
2,694 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 24VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 15 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 16.8 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-ML2-DC48VRELAY GEN PURPOSE DPDT 2A 48V |
4,330 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 48VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 7.5 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 33.6 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
DS2Y-S-DC5VRELAY GENERAL PURPOSE DPDT 2A 5V |
2,568 |
|
Datasheet |
DS2Y | Tube | Obsolete | Through Hole | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 3 ms | 40 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 4 ms | - | -40°C ~ 70°C | 0.5 VDC | - | 3.5 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2Y-S-DC12VRELAY GEN PURPOSE DPDT 2A 12V |
3,851 |
|
Datasheet |
DS2Y | Tube | Obsolete | Through Hole | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 3 ms | 16.7 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 4 ms | - | -40°C ~ 70°C | 1.2 VDC | - | 8.4 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2Y-S-DC24VRELAY GEN PURPOSE DPDT 2A 24V |
3,548 |
|
Datasheet |
DS2Y | Tube | Obsolete | Through Hole | 24VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 3 ms | 8.3 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 4 ms | - | -40°C ~ 70°C | 2.4 VDC | - | 16.8 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2Y-S-DC48VRELAY GEN PURPOSE DPDT 2A 48V |
4,188 |
|
Datasheet |
DS2Y | Tube | Obsolete | Through Hole | 48VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 3 ms | 6.3 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 4 ms | - | -40°C ~ 70°C | 4.8 VDC | - | 33.6 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2Y-SL2-DC5VRELAY GENERAL PURPOSE DPDT 2A 5V |
2,297 |
|
Datasheet |
DS2Y | Tube | Obsolete | Through Hole | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 36 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | - | -40°C ~ 70°C | - | - | 3.5 VDC | - | General Purpose | - | - |
|
|
DS2Y-SL2-DC12VRELAY GEN PURPOSE DPDT 2A 12V |
2,921 |
|
Datasheet |
DS2Y | Tube | Obsolete | Through Hole | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 15 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | - | -40°C ~ 70°C | - | - | 8.4 VDC | - | General Purpose | - | - |
