Signal Relays, Up to 2 Amps
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Mounting Style | Coil Voltage | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Release Time | Coil Current | Coil Type | Contact Form | Features | Termination Style | Operate Time | Seal Rating | Operating Temperature | Must Release Voltage | Coil Insulation | Must Operate Voltage | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
OUAZ-SH-112L,405RELAY TELECOM SPDT 1A 12V |
5,449 |
|
Datasheet |
OUAZ, OEG | Tube | Obsolete | Through Hole | 12VDC | 1 A | 120VAC, 24VDC - Max | 120VA, 24W | 7 ms | 17 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -30°C ~ 70°C | 1.2 VDC | - | 9 VDC | Silver Palladium (AgPd), Gold (Au) | Telecom | - | - |
|
V23079G2011B301RELAY GEN PURPOSE DPDT 2A 4.5V |
3,280 |
|
Datasheet |
V23079, AXICOM | Tape & Reel (TR) | Active | Surface Mount | 4.5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 4 ms | 31.1 mA | Non Latching | DPDT (2 Form C) | - | Gull Wing | 4 ms | - | -40°C ~ 85°C | 0.45 VDC | - | 3.38 VDC | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
|
EE2-3NDRELAY GENERAL PURPOSE DPDT 2A 3V |
3,691 |
|
Datasheet |
EE2 | Tube | Obsolete | Surface Mount | 3VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 1 ms | 66.7 mA | Non Latching | DPDT (2 Form C) | - | Gull Wing | 2 ms | - | -40°C ~ 85°C | 0.3 VDC | - | 2.25 VDC | Silver Alloy, Gold Alloy | General Purpose | - | - |
|
T81N5D312-24RELAY TELECOM SPDT 1A 24V |
9 |
|
Datasheet |
T81 | Tube | Obsolete | Through Hole | 24VDC | 1 A | 125VAC, 60VDC - Max | 125VA, 60W | 7 ms | 18.8 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 5 ms | - | -30°C ~ 60°C | 1.2 VDC | - | 16.8 VDC | Silver Palladium (AgPd), Gold (Au) | Telecom | - | - |
|
|
T81H5D312-05RELAY TELECOM SPDT 1A 5V |
3,614 |
|
Datasheet |
T81 | Tube | Obsolete | Through Hole | 5VDC | 1 A | 125VAC, 60VDC - Max | 125VA, 60W | 7 ms | 40 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 10 ms | - | -30°C ~ 70°C | 0.25 VDC | - | 3.5 VDC | Silver Palladium (AgPd), Gold (Au) | Telecom | - | - |
|
|
OUAZ-SH-105L,405RELAY TELECOM SPDT 1A 5V |
1,371 |
|
Datasheet |
OUAZ, OEG | Tube | Obsolete | Through Hole | 5VDC | 1 A | 120VAC, 24VDC - Max | 120VA, 24W | 7 ms | 40 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -30°C ~ 70°C | 0.5 VDC | - | 3.75 VDC | Silver Palladium (AgPd), Gold (Au) | Telecom | - | - |
|
|
OUAZ-SH-124L,900RELAY TELECOM SPDT 1A 24V |
24,144 |
|
Datasheet |
OUAZ, OEG | Tube | Obsolete | Through Hole | 24VDC | 1 A | 120VAC, 24VDC - Max | 120VA, 24W | 7 ms | 8.6 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -30°C ~ 70°C | 2.4 VDC | - | 18 VDC | Silver Palladium (AgPd), Gold (Au) | Telecom | - | - |
|
|
V23079G1001B301RELAY GENERAL PURPOSE DPDT 2A 5V |
4,997 |
|
Datasheet |
V23079, AXICOM | Tape & Reel (TR) | Active | Surface Mount | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 4 ms | 28 mA | Non Latching | DPDT (2 Form C) | - | Gull Wing | 4 ms | - | -40°C ~ 85°C | 0.5 VDC | - | 3.75 VDC | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
|
TQ2SS-L2-12V-ZRELAY TELECOM DPDT 2A 12V |
1,500 |
|
Datasheet |
TQ-SMD | Tape & Reel (TR) | Active | Surface Mount | 12VDC | 2 A | 125VAC, 220VDC - Max | 250VA, 440W | 4 ms | 11.7 mA | Latching, Dual Coil | DPDT (2 Form C) | - | Gull Wing | 4 ms | - | -40°C ~ 85°C | - | - | 9 VDC | Silver Nickel (AgNi), Gold (Au) | Telecom | - | - |
|
C93450RELAY TELECOM DPDT 2A 5V |
3,140 |
|
Datasheet |
MT2, AXICOM | Tube | Obsolete | Through Hole | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 3 ms | 110 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 5 ms | - | -55°C ~ 85°C | 0.5 VDC | - | 3.3 VDC | Silver Nickel (AgNi), Gold (Au) | Telecom | - | - |
|
|
C93422RELAY TELECOM DPDT 2A 5V |
978 |
|
Datasheet |
MT2, AXICOM | Tube | Obsolete | Through Hole | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 3 ms | 80 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 5 ms | - | -55°C ~ 85°C | 0.5 VDC | - | 3.3 VDC | Silver Nickel (AgNi), Gold (Au) | Telecom | - | - |
|
|
C93431RELAY TELECOM DPDT 2A 24V |
6,641 |
|
Datasheet |
MT2, AXICOM | Tube | Obsolete | Through Hole | 24VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 3 ms | 23 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 5 ms | - | -55°C ~ 85°C | 2.4 VDC | - | 15.6 VDC | Silver Nickel (AgNi), Gold (Au) | Telecom | - | - |
|
|
OUAZ-SH-112D,405RELAY TELECOM SPDT 1A 12V |
930 |
|
Datasheet |
OUAZ, OEG | Tube | Obsolete | Through Hole | 12VDC | 1 A | 120VAC, 24VDC - Max | 120VA, 24W | 7 ms | 37.5 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 5 ms | Sealed - Fully | -30°C ~ 60°C | 0.6 VDC | - | 8.4 VDC | Silver Palladium (AgPd), Gold (Au) | Telecom | - | - |
|
HY1Z-5VRELAY TELECOM SPDT 1A 5V |
3,682 |
|
Datasheet |
HY | Tube | Obsolete | Through Hole | 5VDC | 1 A | 60VDC - Max | 60W | 4 ms | 40 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 5 ms | Sealed - Fully | -40°C ~ 70°C | 0.5 VDC | - | 3.75 VDC | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
OUAZ-SS-109L,900RELAY TELECOM SPDT 1A 9V |
1,488 |
|
Datasheet |
OUAZ, OEG | Tube | Obsolete | Through Hole | 9VDC | 1 A | 120VAC, 24VDC - Max | 120VA, 24W | 7 ms | 22.5 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 10 ms | Sealed - Flux Protection | -30°C ~ 70°C | 0.9 VDC | - | 6.75 VDC | Silver Palladium (AgPd), Gold (Au) | Telecom | - | - |
|
6-1462037-8RELAY TELECOM DPDT 2A 12V |
4,710 |
|
Datasheet |
IM, AXICOM | Tape & Reel (TR) | Active | Surface Mount | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 3 ms | 8.3 mA | Latching, Single Coil | DPDT (2 Form C) | - | J Lead | 3 ms | Sealed - Hermetically | -40°C ~ 85°C | - | - | 9 VDC | Palladium (Pd), Ruthenium (Ru), Gold (Au) | Telecom | - | - |
|
OUAZ-SH-124DZ,800RELAY GEN PURP |
1,924 |
|
Datasheet |
- | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
OUAZ-SH-112L,900RELAY TELECOM SPDT 1A 12V |
1,583 |
|
Datasheet |
OUAZ, OEG | Tube | Obsolete | Through Hole | 12VDC | 1 A | 120VAC, 24VDC - Max | 120VA, 24W | 7 ms | 17 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -30°C ~ 70°C | 1.2 VDC | - | 9 VDC | Silver Palladium (AgPd), Gold (Au) | Telecom | - | - |
|
|
OUAZ-SH-112D,900RELAY TELECOM SPDT 1A 12V |
477 |
|
Datasheet |
OUAZ, OEG | Tube | Obsolete | Through Hole | 12VDC | 1 A | 120VAC, 24VDC - Max | 120VA, 24W | 7 ms | 37.5 mA | Non Latching | SPDT (1 Form C) | - | PC Pin | 5 ms | Sealed - Fully | -30°C ~ 60°C | 0.6 VDC | - | 8.4 VDC | Silver Palladium (AgPd), Gold (Au) | Telecom | - | - |
|
1422002-8RELAY GEN PURPOSE DPDT 2A 2.4V |
3,130 |
|
Datasheet |
V23079, AXICOM | Bulk | Active | Through Hole | 2.4VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 4 ms | 58.5 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 4 ms | - | -40°C ~ 85°C | - | - | - | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
