Silicon Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Capacitance | Tolerance | Voltage - Breakdown | ESR (Equivalent Series Resistance) | ESL (Equivalent Series Inductance) | Applications | Features | Operating Temperature | Height | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SC33303440CAP SILICON 333PF 20% 100V SMD |
700 |
|
Datasheet |
SC | Nonstandard Chip | Bulk | Active | 333 pF | ±20% | 100 V | - | - | High Temperature | High Reliability | -65°C ~ 200°C | 0.006" (0.15mm) | 0.040" L x 0.040" W (1.02mm x 1.02mm) |
|
|
SC00821518CAP SILICON 8.2PF 20% 100V SMD |
300 |
|
Datasheet |
SC | Nonstandard Chip | Bulk | Active | 8.2 pF | ±20% | 100 V | - | - | High Temperature | High Reliability | -65°C ~ 200°C | 0.006" (0.15mm) | 0.018" L x 0.018" W (0.46mm x 0.46mm) |
|
MA4M3100CAP SILICON 100PF 50V SMD |
1,000 |
|
Datasheet |
4M | Nonstandard Chip | Tray | Active | 100 pF | - | 50 V | - | - | - | High Reliability | -55°C ~ 200°C | 0.008" (0.20mm) | 0.019" L x 0.019" W (0.50mm x 0.50mm) |
|
|
MA4M3030CAP SILICON 30PF 200V SMD |
300 |
|
Datasheet |
4M | Nonstandard Chip | Tray | Active | 30 pF | - | 200 V | - | - | - | High Reliability | -55°C ~ 200°C | 0.008" (0.20mm) | 0.019" L x 0.019" W (0.50mm x 0.50mm) |
|
939114424610-T3NCAP SILICON 0.1UF 15% 11V 0402 |
878 |
|
Datasheet |
BBSC | 0402 (1005 Metric) | Tape & Reel (TR) | Active | 0.1 µF | ±15% | 11 V | 500 mOhms | 100pH | High Stability | High Reliability, Low Profile | -55°C ~ 150°C | 0.006" (0.14mm) | 0.047" L x 0.028" W (1.20mm x 0.70mm) |
|
|
935156722456-T3SCAP SILICON 5600PF 15% 30V 0201 |
805 |
|
Datasheet |
ULSC | 0201 (0603 Metric) | Tape & Reel (TR) | Active | 5600 pF | ±15% | 30 V | 500 mOhms | 100pH | High Stability | High Reliability, Low Profile | -55°C ~ 150°C | 0.006" (0.14mm) | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
|
|
935156724547-T3NC-NEW |
960 |
|
Datasheet |
ULSC | 0402 (1005 Metric) | Tape & Reel (TR) | Active | 0.047 µF | - | 30 V | - | - | High Stability | High Reliability | -55°C ~ 150°C | 0.004" (0.10mm) | 0.047" L x 0.028" W (1.20mm x 0.70mm) |
|
|
935153521310-T3TCAP SILICON 100PF 15% 150V 0202 |
867 |
|
Datasheet |
UWSC | 0202 (0505 Metric) | Tape & Reel (TR) | Active | 100 pF | ±15% | 150 V | 14 mOhms | 6pH | High Stability, Vertical Silicon Cap, Wirebond | High Reliability, Low Profile | -55°C ~ 150°C | 0.011" (0.27mm) | 0.020" L x 0.020" W (0.50mm x 0.50mm) |
|
|
BTD1RVFLT27N102RASMIDSERIES, 3.6V, 1000PF, DSN0 |
488 |
|
Datasheet |
RASMID™ | 01005 (0402 Metric) | Tape & Reel (TR) | Active | 1000 pF | ±15% | - | - | - | - | High Reliability, Low Profile | -55°C ~ 150°C | 0.008" (0.20mm) | 0.016" L x 0.008" W (0.40mm x 0.20mm) |
|
935131424522CAP SILICON 0.022UF 15% 11V 0402 |
182 |
|
Datasheet |
HSSC | 0402 (1005 Metric) | Cut Tape (CT) | Discontinued at Digi-Key | 0.022 µF | ±15% | 11 V | 400 mOhms | 100pH | High Stability | High Reliability | -55°C ~ 150°C | 0.016" (0.41mm) | 0.047" L x 0.028" W (1.20mm x 0.70mm) |
|
|
9047RKCAP SILICON 47PF 10% 50V SMD |
800 |
|
Datasheet |
90 | Nonstandard Chip | Tray | Active | 47 pF | ±10% | - | - | - | High Stability | High Reliability | -55°C ~ 150°C | 0.006" (0.15mm) | 0.020" L x 0.020" W (0.51mm x 0.51mm) |
|
|
935132424533CAP SILICON 0.033UF 15% 11V 0402 |
935 |
|
Datasheet |
HTSC | 0402 (1005 Metric) | Cut Tape (CT) | Discontinued at Digi-Key | 0.033 µF | ±15% | 11 V | 400 mOhms | 100pH | High Temperature | High Reliability | -55°C ~ 200°C | 0.016" (0.41mm) | 0.047" L x 0.028" W (1.20mm x 0.70mm) |
|
|
935133424522CAP SILICON 0.022UF 15% 11V 0402 |
1,011 |
|
Datasheet |
XTSC | 0402 (1005 Metric) | Cut Tape (CT) | Discontinued at Digi-Key | 0.022 µF | ±15% | 11 V | 400 mOhms | 100pH | High Temperature | High Reliability | -55°C ~ 250°C | 0.016" (0.41mm) | 0.047" L x 0.028" W (1.20mm x 0.70mm) |
|
|
MA4M2020CAP SILICON 20PF 200V SMD |
1,000 |
|
Datasheet |
4M | Nonstandard Chip | Tray | Active | 20 pF | - | 200 V | - | - | - | High Reliability | -55°C ~ 200°C | 0.008" (0.20mm) | 0.022" L x 0.022" W (0.56mm x 0.56mm) |
|
|
9123RKCAP SILICON 23PF 10% 100V SMD |
400 |
|
Datasheet |
91 | Nonstandard Chip | Tray | Active | 23 pF | ±10% | - | - | - | High Stability | High Reliability | -55°C ~ 150°C | 0.006" (0.15mm) | 0.020" L x 0.020" W (0.51mm x 0.51mm) |
|
|
935133424533CAP SILICON 0.033UF 15% 11V 0402 |
980 |
|
Datasheet |
XTSC | 0402 (1005 Metric) | Cut Tape (CT) | Discontinued at Digi-Key | 0.033 µF | ±15% | 11 V | 400 mOhms | 100pH | High Temperature | High Reliability | -55°C ~ 250°C | 0.016" (0.41mm) | 0.047" L x 0.028" W (1.20mm x 0.70mm) |
|
90150RKCAP SILICON 150PF 10% SMD |
400 |
|
Datasheet |
90 | Nonstandard SMD | Tray | Active | 150 pF | ±10% | - | - | - | High Stability | - | -55°C ~ 150°C | 0.007" (0.18mm) | 0.015" L x 0.015" W (0.38mm x 0.38mm) |
|
|
9115R0K-BOOCAP SILICON 15PF 100V SMD |
400 |
|
Datasheet |
- | Nonstandard Chip | Tray | Active | 15 pF | - | - | - | - | High Stability | High Reliability | -55°C ~ 150°C | - | 0.020" L x 0.020" W (0.51mm x 0.51mm) |
|
|
935133424547CAP SILICON 0.047UF 15% 11V 0402 |
611 |
|
Datasheet |
XTSC | 0402 (1005 Metric) | Cut Tape (CT) | Discontinued at Digi-Key | 0.047 µF | ±15% | 11 V | 400 mOhms | 100pH | High Temperature | High Reliability | -55°C ~ 250°C | 0.016" (0.41mm) | 0.047" L x 0.028" W (1.20mm x 0.70mm) |
|
|
9112RKCAP SILICON 12PF 10% 100V SMD |
400 |
|
Datasheet |
91 | Nonstandard Chip | Tray | Active | 12 pF | ±10% | - | - | - | High Stability | High Reliability | -55°C ~ 150°C | 0.006" (0.15mm) | 0.020" L x 0.020" W (0.51mm x 0.51mm) |
