    Eaton - Electronics Division CTX25-4P-R

    Part No.:
    CTX25-4P-R
    Manufacturer:
    Eaton - Electronics Division
    Category:
    Arrays, Signal Transformers
    Package:
    Nonstandard
    Datasheet:
    KATY Electronic Technology Co., LTDCTX25-4P-R.pdf
    Description:
    INDUCT ARRAY 2 COIL 25.65UH SMD
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Eaton - Electronics Division
    Series:
    Econo-Pac™
    Package/Case:
    Nonstandard
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Active
    Number of Coils:
    2
    Inductance - Connected In Parallel:
    25.65 µH
    Inductance - Connected In Series:
    102.6 µH
    Tolerance:
    ±20%
    Current Rating - Parallel:
    1.6 A
    Current Rating - Series:
    800 mA
    Current Saturation - Parallel:
    -
    Current Saturation - Series:
    -
    DC Resistance (DCR) - Parallel:
    115mOhm Max
    DC Resistance (DCR) - Series:
    461mOhm Max
    Shielding:
    Unshielded
    Ratings:
    -
    Operating Temperature:
    -40°C ~ 85°C
    Mounting Type:
    Surface Mount
    Size / Dimension:
    0.550" L x 0.550" W (13.97mm x 13.97mm)
    Height:
    0.250" (6.35mm)
