    Panasonic Electronic Components ELK-EV561FE

    Part No.:
    ELK-EV561FE
    Manufacturer:
    Panasonic Electronic Components
    Category:
    EMI/RFI Filters (LC, RC Networks)
    Package:
    1207 (3218 Metric), 3 PC Pad
    Description:
    FILTER LC(T) 560PF ESD SMD
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Panasonic Electronic Components
    Series:
    ELKEV
    Package/Case:
    1207 (3218 Metric), 3 PC Pad
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Obsolete
    Type:
    Low Pass
    Filter Order:
    3rd
    Technology:
    LC (T-Type)
    Number of Channels:
    1
    Center / Cutoff Frequency:
    10MHz (Cutoff)
    Attenuation Value:
    15dB @ 60MHz ~ 1GHz
    Resistance - Channel (Ohms):
    -
    Current:
    2 A
    Values:
    C = 560pF
    ESD Protection:
    Yes
    Operating Temperature:
    -20°C ~ 85°C
    Applications:
    Data Lines for Mobile Devices
    Voltage - Rated:
    22V
    Grade:
    -
    Qualification:
    -
    Mounting Type:
    Surface Mount
    Size / Dimension:
    0.126" L x 0.071" W (3.20mm x 1.80mm)
    Height:
    0.087" (2.20mm)
