FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SIHG039N60E-GE3MOSFET N-CH 600V 63A TO247AC |
500 |
|
Datasheet |
E | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 63A (Tc) | 10V | 39mOhm @ 32A, 10V | 5V @ 250µA | 126 nC @ 10 V | ±30V | 4369 pF @ 100 V | - | 357W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AC |
|
|
SIHG80N60EF-GE3MOSFET N-CH 600V 80A TO247AC |
460 |
|
Datasheet |
EF | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 80A (Tc) | 10V | 32mOhm @ 40A, 10V | 4V @ 250µA | 400 nC @ 10 V | ±30V | 6600 pF @ 100 V | - | 520W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AC |
.jpg)
|
IXTH10P60MOSFET P-CH 600V 10A TO247 |
258 |
|
Datasheet |
- | TO-247-3 | Tube | Active | P-Channel | MOSFET (Metal Oxide) | 600 V | 10A (Tc) | 10V | 1Ohm @ 5A, 10V | 5V @ 250µA | 160 nC @ 10 V | ±20V | 4700 pF @ 25 V | - | 300W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247 (IXTH) |
|
IXFH36N60PMOSFET N-CH 600V 36A TO247AD |
626 |
|
Datasheet |
HiPerFET™, Polar | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 36A (Tc) | 10V | 190mOhm @ 18A, 10V | 5V @ 4mA | 102 nC @ 10 V | ±30V | 5800 pF @ 25 V | - | 650W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AD (IXFH) |
|
IXTT24P20MOSFET P-CH 200V 24A TO268 |
182 |
|
Datasheet |
- | TO-268-3, D3PAK (2 Leads + Tab), TO-268AA | Tube | Active | P-Channel | MOSFET (Metal Oxide) | 200 V | 24A (Tc) | 10V | 110mOhm @ 500mA, 10V | 5V @ 250µA | 150 nC @ 10 V | ±20V | 4200 pF @ 25 V | - | 300W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-268AA |
|
SCT3120AW7TLSICFET N-CH 650V 21A TO263-7 |
788 |
|
Datasheet |
- | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA | Tape & Reel (TR) | Active | N-Channel | SiCFET (Silicon Carbide) | 650 V | 21A (Tc) | - | 156mOhm @ 6.7A, 18V | 5.6V @ 3.33mA | 38 nC @ 18 V | +22V, -4V | 460 pF @ 500 V | - | 100W | 175°C (TJ) | - | - | Surface Mount | TO-263-7 |
|
GP2T080A120HSIC MOSFET 1200V 80M TO-247-4L |
132 |
|
Datasheet |
- | TO-247-4 | Tube | Active | N-Channel | SiCFET (Silicon Carbide) | 1200 V | 35A (Tc) | 20V | 100mOhm @ 20A, 20V | 4V @ 10mA | 61 nC @ 20 V | +25V, -10V | 1377 pF @ 1000 V | - | 188W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-247-4 |
|
|
IXFH50N30Q3MOSFET N-CH 300V 50A TO247AD |
1,803 |
|
Datasheet |
HiPerFET™, Q3 Class | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 300 V | 50A (Tc) | 10V | 80mOhm @ 25A, 10V | 6.5V @ 4mA | 65 nC @ 10 V | ±20V | 3160 pF @ 25 V | - | 690W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AD (IXFH) |
|
IXTT360N055T2MOSFET N-CH 55V 360A TO268 |
730 |
|
Datasheet |
TrenchT2™ | TO-268-3, D3PAK (2 Leads + Tab), TO-268AA | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 360A (Tc) | 10V | 2.4mOhm @ 100A, 10V | 4V @ 250µA | 330 nC @ 10 V | ±20V | 20000 pF @ 25 V | - | 935W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-268AA |
|
|
IXFH18N90PMOSFET N-CH 900V 18A TO247AD |
840 |
|
Datasheet |
HiPerFET™, Polar | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 900 V | 18A (Tc) | 10V | 600mOhm @ 500mA, 10V | 6.5V @ 1mA | 97 nC @ 10 V | ±30V | 5230 pF @ 25 V | - | 540W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AD (IXFH) |
|
|
NTH4L045N065SC1SILICON CARBIDE MOSFET, NCHANNEL |
181 |
|
Datasheet |
- | TO-247-4 | Tube | Active | N-Channel | SiCFET (Silicon Carbide) | 650 V | 55A (Tc) | 15V, 18V | 50mOhm @ 25A, 18V | 4.3V @ 8mA | 105 nC @ 18 V | +22V, -8V | 1870 pF @ 325 V | - | 187W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-247-4L |
|
STW72N60DM2AGMOSFET N-CH 600V 66A TO247 |
528 |
|
Datasheet |
MDmesh™ DM2 | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 66A (Tc) | 10V | 42mOhm @ 33A, 10V | 5V @ 250µA | 121 nC @ 10 V | ±25V | 5508 pF @ 100 V | - | 446W (Tc) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Through Hole | TO-247-3 |
|
|
IXFT340N075T2MOSFET N-CH 75V 340A TO268 |
459 |
|
Datasheet |
HiPerFET™, TrenchT2™ | TO-268-3, D3PAK (2 Leads + Tab), TO-268AA | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 340A (Tc) | 10V | 3.2mOhm @ 100A, 10V | 4V @ 3mA | 300 nC @ 10 V | ±20V | 19000 pF @ 25 V | - | 935W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-268AA |
|
|
IXFH120N20PMOSFET N-CH 200V 120A TO247AD |
302 |
|
Datasheet |
HiPerFET™, Polar | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 120A (Tc) | 10V | 22mOhm @ 500mA, 10V | 5V @ 4mA | 152 nC @ 10 V | ±20V | 6000 pF @ 25 V | - | 714W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-247AD (IXFH) |
|
LSIC1MO120E0160SICFET N-CH 1200V 22A TO247-3 |
2,289 |
|
Datasheet |
- | TO-247-3 | Tube | Active | N-Channel | SiCFET (Silicon Carbide) | 1200 V | 22A (Tc) | 20V | 200mOhm @ 10A, 20V | 4V @ 5mA | 57 nC @ 20 V | +22V, -6V | 870 pF @ 800 V | - | 125W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AD |
|
NTHL050N65S3HFMOSFET N-CH 650V 58A TO247-3 |
389 |
|
Datasheet |
FRFET®, SuperFET® III | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 58A (Tc) | 10V | 50mOhm @ 29A, 10V | 5V @ 1.7mA | 125 nC @ 10 V | ±30V | 5017 pF @ 400 V | - | 378W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247-3 |
|
SCT3160KLHRC11SICFET N-CH 1200V 17A TO247N |
592 |
|
Datasheet |
- | TO-247-3 | Tube | Active | N-Channel | SiCFET (Silicon Carbide) | 1200 V | 17A (Tc) | 18V | 208mOhm @ 5A, 18V | 5.6V @ 2.5mA | 42 nC @ 18 V | +22V, -4V | 398 pF @ 800 V | - | 103W | 175°C (TJ) | Automotive | AEC-Q101 | Through Hole | TO-247N |
|
IXFK44N50PMOSFET N-CH 500V 44A TO264AA |
260 |
|
Datasheet |
HiPerFET™, Polar | TO-264-3, TO-264AA | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 44A (Tc) | 10V | 140mOhm @ 22A, 10V | 5V @ 4mA | 98 nC @ 10 V | ±30V | 5440 pF @ 25 V | - | 658W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-264AA (IXFK) |
|
IXTP94N20X4MOSFET 200V 94A N-CH ULTRA TO220 |
163 |
|
Datasheet |
Ultra X4 | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 94A (Tc) | 10V | 10.6mOhm @ 47A, 10V | 4.5V @ 250µA | 77 nC @ 10 V | ±20V | 5050 pF @ 25 V | - | 360W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220 |
|
|
SCTW40N120G2VSILICON CARBIDE POWER MOSFET 120 |
555 |
|
Datasheet |
- | TO-247-3 | Tube | Active | N-Channel | SiCFET (Silicon Carbide) | 1200 V | 36A (Tc) | 18V | 100mOhm @ 20A, 18V | 4.9V @ 1mA | 61 nC @ 18 V | +22V, -10V | 1233 pF @ 800 V | - | 278W (Tc) | -55°C ~ 200°C (TJ) | - | - | Through Hole | HiP247™ |
