FETs, MOSFETs
| 制造商 | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
全部重置
应用所有
结果:
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R6025JNXC7GMOSFET N-CH 600V 25A TO220FM Rohm Semiconductor |
1,961 | - |
|
Datasheet |
- | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 25A (Tc) | 15V | 182mOhm @ 12.5A, 15V | 7V @ 4.5mA | 57 nC @ 15 V | ±30V | 1900 pF @ 100 V | - | 85W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220FM |
|
R8007AND3FRATLMOSFET N-CH 800V 7A TO252 Rohm Semiconductor |
4,914 | - |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 7A (Tc) | 10V | 1.6Ohm @ 3.5A, 10V | 5V @ 1mA | 28 nC @ 10 V | ±30V | 850 pF @ 25 V | - | 140W (Tc) | 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TO-252 |
|
RCJ700N20TLMOSFET N-CH 200V 70A LPTS Rohm Semiconductor |
926 | - |
|
Datasheet |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 70A (Tc) | 10V | 42.7mOhm @ 35A, 10V | 5V @ 1mA | 125 nC @ 10 V | ±30V | 6900 pF @ 25 V | - | 1.56W (Ta), 40W (Tc) | 150°C (TJ) | - | - | Surface Mount | LPTS |
|
R6024VNX3C16600V 24A TO-220AB, PRESTOMOS WIT Rohm Semiconductor |
1,055 | - |
|
Datasheet |
- | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 24A (Tc) | 10V, 15V | 153mOhm @ 6A, 15V | 6.5V @ 700µA | 38 nC @ 10 V | ±30V | 1800 pF @ 100 V | - | 245W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220AB |
|
R6020ENZ4C13MOSFET N-CH 600V 20A TO247 Rohm Semiconductor |
600 | - |
|
Datasheet |
- | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 20A (Tc) | 10V | 196mOhm @ 9.5A, 10V | 4V @ 1mA | 60 nC @ 10 V | ±20V | 1400 pF @ 25 V | - | 231W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-247 |
|
|
R8008ANJGTLNCH 800V 8A POWER MOSFET : R8008 Rohm Semiconductor |
851 | - |
|
Datasheet |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 8A (Tc) | 10V | 1.03Ohm @ 4A, 10V | 5V @ 1mA | 38 nC @ 10 V | ±30V | 1100 pF @ 25 V | - | 195W (Tc) | 150°C (TJ) | - | - | Surface Mount | TO-263S |
|
|
R6520KNZC17MOSFET N-CH 650V 20A TO3 Rohm Semiconductor |
299 | - |
|
Datasheet |
- | TO-3P-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 20A (Tc) | 10V | 205mOhm @ 9.5A, 10V | 5V @ 630µA | 40 nC @ 10 V | ±20V | 1550 pF @ 25 V | - | 68W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-3PF |
|
|
R6055VNZC17600V 23A TO-3PF, PRESTOMOS WITH Rohm Semiconductor |
420 | - |
|
Datasheet |
- | TO-3P-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 23A (Tc) | 10V, 15V | 71mOhm @ 16A, 15V | 6.5V @ 1.5mA | 80 nC @ 10 V | ±30V | 3700 pF @ 100 V | - | 99W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-3PF |
|
|
R6025JNZC17MOSFET N-CH 600V 25A TO3PF Rohm Semiconductor |
300 | - |
|
Datasheet |
- | TO-3P-3 Full Pack | Bag | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 25A (Tc) | 15V | 182mOhm @ 12.5A, 15V | 7V @ 2.5mA | 57 nC @ 15 V | ±30V | 1900 pF @ 100 V | - | 85W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-3PF |
|
|
R6520ENZC17MOSFET N-CH 650V 20A TO3 Rohm Semiconductor |
300 | - |
|
Datasheet |
- | TO-3P-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 20A (Tc) | 10V | 205mOhm @ 9.5A, 10V | 4V @ 630µA | 61 nC @ 10 V | ±20V | 1400 pF @ 25 V | - | 68W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-3PF |
