Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Material - Core | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Supplier Device Package | Shielding | DC Resistance (DCR) | Inductance | Q @ Freq | Frequency - Self Resonant | Mounting Style | Ratings | Size / Dimension | Features | Operating Temperature | Inductance Frequency - Test | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
7440690180FIXED IND 18UH 1.1A 250 MOHM SMD Würth Elektronik |
523 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.1 A | 1.05A | - | Shielded | 250mOhm Max | 18 µH | - | 7MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.059" (1.50mm) |
|
|
7440690068FIXED IND 6.8UH 1.75A 110MOHM SM Würth Elektronik |
520 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.75 A | 1.65A | - | Shielded | 110mOhm Max | 6.8 µH | - | 15MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.059" (1.50mm) |
|
7440680120FIXED IND 12UH 1.15A 220MOHM SMD Würth Elektronik |
520 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.15 A | 950mA | - | Shielded | 220mOhm Max | 12 µH | - | 22MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
|
|
7440690010FIXED IND 1UH 3.6A 26 MOHM SMD Würth Elektronik |
511 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 3.6 A | 4A | - | Shielded | 26mOhm Max | 1 µH | - | 90MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.059" (1.50mm) |
|
|
7440680047FIXED IND 4.7UH 1.85A 85MOHM SMD Würth Elektronik |
510 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.85 A | 1.55A | - | Shielded | 85mOhm Max | 4.7 µH | - | 55MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
|
|
7440690022FIXED IND 2.2UH 2.8A 45 MOHM SMD Würth Elektronik |
494 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 2.8 A | 2.85A | - | Shielded | 45mOhm Max | 2.2 µH | - | 50MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.059" (1.50mm) |
|
|
7440680033FIXED IND 3.3UH 2A 72 MOHM SMD Würth Elektronik |
491 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 2 A | 1.8A | - | Shielded | 72mOhm Max | 3.3 µH | - | 65MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
|
74407000082FIXED IND 820NH 6A 11 MOHM SMD Würth Elektronik |
480 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 6 A | 5.5A | - | Shielded | 11mOhm Max | 820 nH | - | 200MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.079" (2.00mm) |
|
|
7440700068FIXED IND 6.8UH 2.4A 68 MOHM SMD Würth Elektronik |
449 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 2.4 A | 1.8A | - | Shielded | 68mOhm Max | 6.8 µH | - | 55MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.079" (2.00mm) |
|
|
7440680056FIXED IND 5.6UH 1.5A 120MOHM SMD Würth Elektronik |
441 |
|
Datasheet |
WE-TPC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.5 A | 1.4A | - | Shielded | 120mOhm Max | 5.6 µH | - | 48MHz | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
