Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Material - Core | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Supplier Device Package | Shielding | DC Resistance (DCR) | Inductance | Q @ Freq | Frequency - Self Resonant | Mounting Style | Ratings | Size / Dimension | Features | Operating Temperature | Inductance Frequency - Test | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SDR0604-270YLFIXED IND 27UH 1A 220 MOHM SMD Bourns Inc. |
7,720 |
|
Datasheet |
SDR0604 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±15% | 1 A | 1.3A | - | Unshielded | 220mOhm Max | 27 µH | 28 @ 2.52MHz | 14MHz | Surface Mount | - | 0.228" L x 0.228" W (5.80mm x 5.80mm) | - | -40°C ~ 125°C | 1 kHz | 0.189" (4.80mm) |
|
SDR0403-101KLFIXED IND 100UH 350MA 1.9OHM SMD Bourns Inc. |
7,482 |
|
Datasheet |
SDR0403 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 350 mA | 510mA | - | Unshielded | 1.9Ohm Max | 100 µH | 35 @ 796kHz | 9MHz | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | - | -40°C ~ 125°C | 1 kHz | 0.138" (3.50mm) |
|
|
SDR0604-151KLFIXED IND 150UH 400MA 1.1OHM SMD Bourns Inc. |
7,382 |
|
Datasheet |
SDR0604 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 400 mA | 540mA | - | Unshielded | 1.1Ohm Max | 150 µH | 20 @ 796kHz | 6MHz | Surface Mount | - | 0.228" L x 0.228" W (5.80mm x 5.80mm) | - | -40°C ~ 125°C | 1 kHz | 0.189" (4.80mm) |
|
SDR0403-120MLFIXED IND 12UH 1.05A 210MOHM SMD Bourns Inc. |
6,772 |
|
Datasheet |
SDR0403 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.05 A | 1.6A | - | Unshielded | 210mOhm Max | 12 µH | 28 @ 2.52MHz | 30MHz | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | - | -40°C ~ 125°C | 1 kHz | 0.138" (3.50mm) |
|
SRN6045TA-151MFIXED IND 150UH 750MA 626MOHM SM Bourns Inc. |
6,293 |
|
Datasheet |
SRN6045TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 750 mA | 1.1A | - | Shielded | 626mOhm | 150 µH | 15 @ 1MHz | 6.5MHz | Surface Mount | AEC-Q200 | 0.236" L x 0.236" W (6.00mm x 6.00mm) | - | -55°C ~ 125°C | 1 MHz | 0.177" (4.50mm) |
|
|
SRN6045TA-221MFIXED IND 220UH 600MA 900MOHM SM Bourns Inc. |
6,256 |
|
Datasheet |
SRN6045TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 600 mA | 880mA | - | Shielded | 900mOhm | 220 µH | 15 @ 1MHz | 5MHz | Surface Mount | AEC-Q200 | 0.236" L x 0.236" W (6.00mm x 6.00mm) | - | -55°C ~ 125°C | 1 MHz | 0.177" (4.50mm) |
|
|
SDR0403-4R7MLFIXED IND 4.7UH 1.7A 94 MOHM SMD Bourns Inc. |
6,246 |
|
Datasheet |
SDR0403 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.7 A | 2.6A | - | Unshielded | 94mOhm Max | 4.7 µH | 28 @ 7.96MHz | 50MHz | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | - | -40°C ~ 125°C | 1 kHz | 0.138" (3.50mm) |
|
|
SDR0604-102KLFIXED IND 1MH 120MA 6.8 OHM SMD Bourns Inc. |
6,112 |
|
Datasheet |
SDR0604 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 120 mA | 120mA | - | Unshielded | 6.8Ohm Max | 1 mH | 45 @ 252kHz | 1.5MHz | Surface Mount | - | 0.228" L x 0.228" W (5.80mm x 5.80mm) | - | -40°C ~ 125°C | 1 kHz | 0.189" (4.80mm) |
|
|
SDR0604-3R3MLFIXED IND 3.3UH 2A 70 MOHM SMD Bourns Inc. |
5,942 |
|
Datasheet |
SDR0604 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 2 A | 3.5A | - | Unshielded | 70mOhm Max | 3.3 µH | 22 @ 7.96MHz | 60MHz | Surface Mount | - | 0.228" L x 0.228" W (5.80mm x 5.80mm) | - | -40°C ~ 125°C | 1 kHz | 0.189" (4.80mm) |
|
SDR0302-181KLFIXED IND 180UH 185MA 5 OHM SMD Bourns Inc. |
5,056 |
|
Datasheet |
SDR0302 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 185 mA | 210mA | - | Unshielded | 5Ohm Max | 180 µH | 45 @ 796kHz | 8.5MHz | Surface Mount | - | 0.118" L x 0.110" W (3.00mm x 2.80mm) | - | -40°C ~ 125°C | 1 kHz | 0.110" (2.80mm) |
