Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRN6045-8R2YFIXED IND 8.2UH 2.7A 55 MOHM SMD Bourns Inc. |
23,054 |
|
Datasheet |
SRN6045 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 8.2 µH | ±30% | 2.7 A | 3.3A | Shielded | 55mOhm Max | 15 @ 7.96MHz | 18MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.177" (4.50mm) |
|
SRN5040TA-101KFIXED IND 100UH 720MA 560MOHM SM Bourns Inc. |
14,806 |
|
Datasheet |
SRN5040TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±10% | 720 mA | 750mA | Shielded | 560mOhm | 15 @ 100kHz | 7MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.195" L x 0.195" W (4.95mm x 4.95mm) | 0.161" (4.10mm) |
|
|
SRN5040TA-330MFIXED IND 33UH 1.2A 180 MOHM SMD Bourns Inc. |
5,150 |
|
Datasheet |
SRN5040TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±20% | 1.2 A | 1.3A | Shielded | 180mOhm | 15 @ 100kHz | 13MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.195" L x 0.195" W (4.95mm x 4.95mm) | 0.161" (4.10mm) |
|
|
SRN5040TA-100MFIXED IND 10UH 2.2A 56 MOHM SMD Bourns Inc. |
4,591 |
|
Datasheet |
SRN5040TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 2.2 A | 2.52A | Shielded | 56mOhm | 15 @ 100kHz | 26MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.195" L x 0.195" W (4.95mm x 4.95mm) | 0.161" (4.10mm) |
|
|
SRN5040TA-1R0MFIXED IND 1UH 5A 12 MOHM SMD Bourns Inc. |
2,068 |
|
Datasheet |
SRN5040TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1 µH | ±20% | 5 A | 7.5A | Shielded | 12mOhm | 15 @ 100kHz | 140MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.195" L x 0.195" W (4.95mm x 4.95mm) | 0.161" (4.10mm) |
|
|
SRN6045-221MFIXED IND 220UH 600MA 1.18OHM SM Bourns Inc. |
1,488 |
|
Datasheet |
SRN6045 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 220 µH | ±20% | 600 mA | 700mA | Shielded | 1.18Ohm Max | 25 @ 796kHz | 4MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.177" (4.50mm) |
|
|
SRN5040TA-470KFIXED IND 47UH 1A 270 MOHM SMD Bourns Inc. |
1,488 |
|
Datasheet |
SRN5040TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±10% | 1 A | 1.1A | Shielded | 270mOhm | 15 @ 100kHz | 11MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.195" L x 0.195" W (4.95mm x 4.95mm) | 0.161" (4.10mm) |
|
|
SRN5040TA-220MFIXED IND 22UH 1.5A 123 MOHM SMD Bourns Inc. |
1,205 |
|
Datasheet |
SRN5040TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 1.5 A | 1.62A | Shielded | 123mOhm | 15 @ 100kHz | 16MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.195" L x 0.195" W (4.95mm x 4.95mm) | 0.161" (4.10mm) |
|
SRN4018BTA-4R7MIND,4X4X1.6MM,4.7UH20%,1.7A,SHD Bourns Inc. |
2,493 |
|
Datasheet |
SRN4018BTA | 1616 (4040 Metric) | Tape & Reel (TR) | Active | Wirewound | Ferrite | 4.7 µH | ±20% | 1.7 A | 2A | Shielded | 70mOhm | 10 @ 100kHz | 35MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.071" (1.80mm) |
|
SRP2512A-1R0MFIXED IND 1UH 3.5A 49 MOHM SMD Bourns Inc. |
11,026 |
|
Datasheet |
SRP2512A | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 1 µH | ±20% | 3.5 A | 4.4A | Shielded | 49mOhm Max | 39 @ 1MHz | 82MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1008 | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.047" (1.20mm) |
