Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Material - Core | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Supplier Device Package | Shielding | DC Resistance (DCR) | Inductance | Q @ Freq | Frequency - Self Resonant | Mounting Style | Ratings | Size / Dimension | Features | Operating Temperature | Inductance Frequency - Test | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B82432C1222K000FIXED IND 2.2UH 480MA 430MOHM SM |
22,387 |
|
Datasheet |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 480 mA | - | 1812 (4532 Metric) | Unshielded | 430mOhm Max | 2.2 µH | 40 @ 7.96MHz | 90MHz | Surface Mount | AEC-Q200 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | - | -55°C ~ 125°C | 1 MHz | 0.134" (3.40mm) |
|
CDRH4D28NP-3R3NCFIXED IND 3.3UH 1.57A 49.2 MOHM |
18,404 |
|
Datasheet |
CDRH4D28 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±30% | 1.57 A | - | - | Shielded | 49.2mOhm Max | 3.3 µH | - | - | Surface Mount | - | 0.185" L x 0.185" W (4.70mm x 4.70mm) | - | -40°C ~ 100°C | 100 kHz | 0.118" (3.00mm) |
|
CDRH6D38NP-150NCFIXED IND 15UH 1.6A 57 MOHM SMD |
8,811 |
|
Datasheet |
CDRH6D38 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±30% | 1.6 A | - | - | Shielded | 57mOhm Max | 15 µH | - | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | - | -40°C ~ 100°C | 100 kHz | 0.157" (4.00mm) |
|
0630CDMCCDS-150MCFIXED IND 15UH 3.3A 115MOHM SMD |
8,661 |
|
Datasheet |
0630CDMC/DS | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal | ±20% | 3.3 A | 4.3A | SMD | Shielded | 115mOhm Max | 15 µH | - | - | Surface Mount | - | 0.276" L x 0.260" W (7.00mm x 6.60mm) | - | -55°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
|
CDRH6D38NP-180NCFIXED IND 18UH 1.5A 92 MOHM SMD |
3,954 |
|
Datasheet |
CDRH6D38 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±30% | 1.5 A | - | - | Shielded | 92mOhm Max | 18 µH | - | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | - | -40°C ~ 100°C | 100 kHz | 0.157" (4.00mm) |
|
AIUR-02H-221KFIXED IND 220UH 500MA 340MOHM TH |
3,408 |
|
Datasheet |
AIUR-02H | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | ±10% | 500 mA | 1A | - | Unshielded | 340mOhm Max | 220 µH | 20 @ 790kHz | - | Through Hole | - | 0.335" Dia (8.50mm) | - | -40°C ~ 125°C | 1 kHz | 0.472" (12.00mm) |
|
NR10050T330MFIXED IND 33UH 2.1A 85.8MOHM SMD |
3,022 |
|
Datasheet |
NR | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 2.1 A | 2.5A | - | Unshielded | 85.8mOhm Max | 33 µH | - | 8.2MHz | Surface Mount | - | 0.394" L x 0.386" W (10.00mm x 9.80mm) | - | -25°C ~ 105°C | 100 kHz | 0.197" (5.00mm) |
|
|
0630CDMCDDS-6R8MCFIXED IND 6.8UH 5A 48 MOHM SMD |
2,758 |
|
Datasheet |
0630CDMCD/DS | Nonstandard | Tape & Reel (TR) | Active | Molded | Carbonyl Powder | ±20% | 4.8 A | 7.2A | SMD | Shielded | 60mOhm Max | 6.8 µH | - | - | Surface Mount | - | 0.276" L x 0.260" W (7.00mm x 6.60mm) | - | -55°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
0630CDMCCDS-R68MCFIXED IND 680NH 16.5A 5.3MOHM SM |
1,478 |
|
Datasheet |
0630CDMC/DS | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal | ±20% | 16.5 A | 20A | SMD | Shielded | 5.3mOhm Max | 680 nH | - | - | Surface Mount | - | 0.276" L x 0.260" W (7.00mm x 6.60mm) | - | -55°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
IHLP2525CZER220M51FIXED IND 22UH 2.8A 174 MOHM SMD |
1,078 |
|
Datasheet |
IHLP-2525CZ-51 | Nonstandard | Tape & Reel (TR) | Active | Molded | - | ±20% | 2.8 A | 2.2A | - | Shielded | 174mOhm Max | 22 µH | - | 8.3MHz | Surface Mount | - | 0.270" L x 0.255" W (6.86mm x 6.47mm) | - | -55°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
CLF5030NIT-150M-DFIXED IND 15UH 1.3A 168MOHM SMD |
5,822 |
|
Datasheet |
CLF-NI-D | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.3 A | 1.3A | - | Shielded | 168mOhm Max | 15 µH | - | - | Surface Mount | AEC-Q200 | 0.209" L x 0.197" W (5.30mm x 5.00mm) | - | -55°C ~ 150°C | 100 kHz | 0.118" (3.00mm) |
|
SRR0805-101KFIXED IND 100UH 500MA 600MOHM SM |
3,179 |
|
Datasheet |
SRR0805 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 500 mA | 700mA | - | Shielded | 600mOhm Max | 100 µH | 45 @ 796kHz | 7.5MHz | Surface Mount | - | 0.413" L x 0.315" W (10.50mm x 8.00mm) | - | -40°C ~ 125°C | 1 kHz | 0.185" (4.70mm) |
|
P0751.682NLTFIXED IND 6.8UH 4.4A 44 MOHM SMD |
2,810 |
|
Datasheet |
P0751NL | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | ±20% | 4.4 A | 4.6A | - | Unshielded | 44mOhm Max | 6.8 µH | - | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | - | -40°C ~ 130°C | 100 kHz | 0.215" (5.46mm) |
|
|
CLF5030NIT-221M-DFIXED IND 220UH 280MA 3.036 OHM |
2,231 |
|
Datasheet |
CLF-NI-D | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 280 mA | 380mA | - | Shielded | 3.036Ohm Max | 220 µH | - | - | Surface Mount | AEC-Q200 | 0.209" L x 0.197" W (5.30mm x 5.00mm) | - | -55°C ~ 150°C | 100 kHz | 0.118" (3.00mm) |
|
IHLP2020CZERR68M5AFIXED IND 680NH 11.3A 9.74 MOHM |
2,204 |
|
Datasheet |
IHLP-2020CZ-5A | Nonstandard | Tape & Reel (TR) | Active | Molded | - | ±20% | 11.3 A | 8.2A | - | Shielded | 9.74mOhm Max | 680 nH | - | 77.7MHz | Surface Mount | AEC-Q200 | 0.204" L x 0.204" W (5.18mm x 5.18mm) | - | -55°C ~ 155°C | 100 kHz | 0.118" (3.00mm) |
|
|
CLF5030NIT-1R0N-DFIXED IND 1UH 3.7A 24.7MOHM SMD |
2,201 |
|
Datasheet |
CLF-NI-D | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 3.7 A | 5A | - | Shielded | 24.7mOhm Max | 1 µH | - | - | Surface Mount | AEC-Q200 | 0.209" L x 0.197" W (5.30mm x 5.00mm) | - | -55°C ~ 150°C | 100 kHz | 0.118" (3.00mm) |
|
|
SRR0805-100MFIXED IND 10UH 1.5A 100 MOHM SMD |
2,090 |
|
Datasheet |
SRR0805 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.5 A | 2.2A | - | Shielded | 100mOhm Max | 10 µH | 40 @ 2.52MHz | 28MHz | Surface Mount | - | 0.413" L x 0.315" W (10.50mm x 8.00mm) | - | -40°C ~ 125°C | 1 kHz | 0.185" (4.70mm) |
|
SRR0603-470KLFIXED IND 47UH 500MA 550MOHM SMD |
1,384 |
|
Datasheet |
SRR0603 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 500 mA | 730mA | - | Shielded | 550mOhm Max | 47 µH | 13 @ 2.52MHz | 13MHz | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | - | -40°C ~ 125°C | 1 kHz | 0.130" (3.30mm) |
|
SRR0604-150MLFIXED IND 15UH 1.1A 130 MOHM SMD |
9,023 |
|
Datasheet |
SRR0604 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.1 A | 1.45A | - | Shielded | 130mOhm Max | 15 µH | 18 @ 2.52MHz | 30MHz | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | - | -40°C ~ 125°C | 1 kHz | 0.189" (4.80mm) |
|
AMRU00060630100MA1FIXED IND 10UH 4A 68 MOHM SMD |
7,184 |
|
Datasheet |
AMRU | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Metal | ±20% | 4 A | 5A | - | Shielded | 68mOhm Max | 10 µH | - | - | Surface Mount | AEC-Q200 | 0.287" L x 0.268" W (7.30mm x 6.80mm) | - | -40°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
