Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1812PS-124KRCFIXED IND 120UH 600MA 1.45OHM SM Coilcraft |
194 |
|
Datasheet |
1812PS | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ceramic, Ferrite | 120 µH | ±10% | 600 mA | 230mA | Shielded | 1.45Ohm Max | 60 @ 1MHz | 12MHz | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | 1812 | 0.231" L x 0.196" W (5.87mm x 4.98mm) | 0.150" (3.80mm) |
|
|
1812PS-334KRCFIXED IND 330UH 310MA 4.85OHM SM Coilcraft |
179 |
|
Datasheet |
1812PS | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ceramic, Ferrite | 330 µH | ±10% | 310 mA | 150mA | Shielded | 4.85Ohm Max | 60 @ 1MHz | 5.5MHz | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | 1812 | 0.231" L x 0.196" W (5.87mm x 4.98mm) | 0.150" (3.80mm) |
|
|
1812PS-102JRCFIXED IND 1UH 2.7A 50MOHM SM Coilcraft |
3,345 |
|
Datasheet |
1812PS | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ceramic, Ferrite | 1 µH | ±5% | 2.7 A | 2.5A | Shielded | 50mOhm Max | 35 @ 1MHz | 685MHz | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | 1812 | 0.231" L x 0.196" W (5.87mm x 4.98mm) | 0.150" (3.80mm) |
|
|
1812PS-222JRCFIXED IND 2.2UH 2.4A 70MOHM SM Coilcraft |
2,962 |
|
Datasheet |
1812PS | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ceramic, Ferrite | 2.2 µH | ±5% | 2.4 A | 1.7A | Shielded | 70mOhm Max | 38 @ 1MHz | 270MHz | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | 1812 | 0.231" L x 0.196" W (5.87mm x 4.98mm) | 0.150" (3.80mm) |
|
|
1812PS-103JRCFIXED IND 10UH 1.7A 170MOHM SM Coilcraft |
2,418 |
|
Datasheet |
1812PS | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ceramic, Ferrite | 10 µH | ±5% | 1.7 A | 900mA | Shielded | 170mOhm Max | 40 @ 1MHz | 120MHz | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | 1812 | 0.231" L x 0.196" W (5.87mm x 4.98mm) | 0.150" (3.80mm) |
|
|
1812PS-223JRCFIXED IND 22UH 1.2A 330MOHM SM Coilcraft |
343 |
|
Datasheet |
1812PS | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ceramic, Ferrite | 22 µH | ±5% | 1.2 A | 540mA | Shielded | 330mOhm Max | 40 @ 1MHz | 45MHz | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | 1812 | 0.231" L x 0.196" W (5.87mm x 4.98mm) | 0.150" (3.80mm) |
|
|
1812PS-332JRCFIXED IND 3.3UH 2.3A 90MOHM SM Coilcraft |
339 |
|
Datasheet |
1812PS | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ceramic, Ferrite | 3.3 µH | ±5% | 2.3 A | 1.4A | Shielded | 90mOhm Max | 40 @ 1MHz | 225MHz | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | 1812 | 0.231" L x 0.196" W (5.87mm x 4.98mm) | 0.150" (3.80mm) |
|
MSS6132-153MLCPOWER INDUCTOR, SHIELDED, 20% TO Coilcraft |
21,533 |
|
Datasheet |
MSS6132 | Nonstandard | Strip | Active | Drum Core | Ferrite | 15 µH | ±20% | 1.65 A | 1.16A | Shielded | 106mOhm Max | - | 27MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.240" L x 0.240" W (6.10mm x 6.10mm) | 0.126" (3.20mm) |
|
|
MSS6132-472MLCPOWER INDUCTOR, SHIELDED, 20% TO Coilcraft |
17,460 |
|
Datasheet |
MSS6132 | Nonstandard | Strip | Active | Drum Core | Ferrite | 4.7 µH | ±20% | 2.3 A | 2.18A | Shielded | 43mOhm Max | - | 65MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.240" L x 0.240" W (6.10mm x 6.10mm) | 0.126" (3.20mm) |
|
|
MSS6132-103MLCPOWER INDUCTOR, SHIELDED, 20% TO Coilcraft |
14,488 |
|
Datasheet |
MSS6132 | Nonstandard | Strip | Active | Drum Core | Ferrite | 10 µH | ±20% | 1.9 A | 1.36A | Shielded | 70mOhm Max | - | 39MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.240" L x 0.240" W (6.10mm x 6.10mm) | 0.126" (3.20mm) |
