Triac, SCR Output Optoisolators
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Output Type | Zero Crossing Circuit | Number of Channels | Voltage - Isolation | Voltage - Off State | Static dV/dt (Min) | Current - LED Trigger (Ift) (Max) | Current - On State (It (RMS)) (Max) | Current - Hold (Ih) | Turn On Time | Voltage - Forward (Vf) (Typ) | Current - DC Forward (If) (Max) | Operating Temperature | Mounting Type | Supplier Device Package | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TLP3062A(LF1,FOPTO TRIAC COUPLER; ZERO-VOLTAGE Toshiba Semiconductor and Storage |
30 |
|
Datasheet |
- | 6-SMD (5 Leads), Gull Wing | Tube | Active | Triac | Yes | 1 | 5000Vrms | 600 V | 2kV/µs (Typ) | 10mA | 100 mA | 600µA (Typ) | - | 1.15V | 50 mA | -40°C ~ 100°C | Surface Mount | 6-SO, 5 Lead | CQC, cUR, UR |
|
TLP3083F(FPHOTOCOUPLER Toshiba Semiconductor and Storage |
50 |
|
Datasheet |
- | 6-DIP (0.400", 10.16mm), 5 Leads | Tube | Active | Triac | Yes | 1 | 5000Vrms | 800 V | 2kV/µs (Typ) | 5mA | 100 mA | 600µA | - | 1.15V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | CQC, CSA, cUL, UL, VDE |
|
|
TLP3083F(LF4,FPHOTOTRIAC; ZVC; WIDE CREEPAGE; Toshiba Semiconductor and Storage |
50 |
|
Datasheet |
- | 6-SMD, Gull Wing, 5 Leads | Tube | Active | Triac | Yes | 1 | 5000Vrms | 800 V | 2kV/µs (Typ) | 5mA | 100 mA | 600µA | - | 1.15V | 50 mA | -40°C ~ 100°C | Surface Mount | 6-SMD | CQC, CSA, cUL, UL, VDE |
|
|
TLP3083F(D4,LF4FPHOTOTRIAC; ZVC; WIDE CREEPAGE; Toshiba Semiconductor and Storage |
47 |
|
Datasheet |
- | 6-SMD, Gull Wing, 5 Leads | Tube | Active | Triac | Yes | 1 | 5000Vrms | 800 V | 2kV/µs (Typ) | 5mA | 100 mA | 600µA | - | 1.15V | 50 mA | -40°C ~ 100°C | Surface Mount | 6-SMD | CQC, CSA, cUL, UL, VDE |
|
TLP265J(EX36 PB-F PHOTOCOUPLER SO6 ROHS B Toshiba Semiconductor and Storage |
3,657 |
|
Datasheet |
- | 6-SOIC (0.173", 4.40mm Width), 4 Leads | Tube | Active | Triac | No | 1 | 3750Vrms | 600 V | 500V/µs (Typ) | 10mA | 70 mA | 1mA (Typ) | 20µs | 1.27V | 50 mA | -40°C ~ 100°C | Surface Mount | 6-SOP | CQC, cUR, UR |
|
|
TLP3073(FOPTO TRIAC COUPLER; NON-ZERO-VOL Toshiba Semiconductor and Storage |
4,818 |
|
Datasheet |
- | 6-DIP (0.300", 7.62mm), 5 Leads | Tube | Active | Triac | No | 1 | 5000Vrms | 800 V | 2kV/µs (Typ) | 5mA | 100 mA | 1mA (Typ) | - | 1.15V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | CQC, cUR, UR |
|
|
TLP3083F(D4,FPHOTOCOUPLER Toshiba Semiconductor and Storage |
23 |
|
Datasheet |
- | 6-DIP (0.400", 10.16mm), 5 Leads | Tube | Active | Triac | Yes | 1 | 5000Vrms | 800 V | 2kV/µs (Typ) | 5mA | 100 mA | 600µA | - | 1.15V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | CQC, CSA, cUL, UL, VDE |
|
TLP525GFOPTOISOLATOR 2.5KV TRIAC 4DIP Toshiba Semiconductor and Storage |
4,396 |
|
- |
- | 4-DIP (0.300", 7.62mm) | Tube | Obsolete | Triac | No | 1 | 2500Vrms | 400 V | 200V/µs | 10mA | 100 mA | 200µA (Typ) | - | 1.15V | 50 mA | -40°C ~ 100°C | Through Hole | 4-DIP | UR |
|
TLP160G(TPR,U,F)OPTOISOLATOR 2.5KV TRIAC 6MFSOP Toshiba Semiconductor and Storage |
3,309 |
|
- |
- | 6-SOIC (0.173", 4.40mm Width), 4 Leads | Tape & Reel (TR) | Obsolete | Triac | No | 1 | 2500Vrms | 400 V | 200V/µs | 10mA | 70 mA | 600µA (Typ) | 30µs | 1.15V | 50 mA | -40°C ~ 100°C | Surface Mount | 6-MFSOP, 4 Lead | UR |
|
|
TLP161J(TPR,U,C,F)OPTOISOLATOR 2.5KV TRIAC 6MFSOP Toshiba Semiconductor and Storage |
2,320 |
|
- |
- | 6-SOIC (0.173", 4.40mm Width), 4 Leads | Tape & Reel (TR) | Obsolete | Triac | Yes | 1 | 2500Vrms | 600 V | 200V/µs | 10mA | 70 mA | 600µA (Typ) | - | 1.15V | 50 mA | -40°C ~ 100°C | Surface Mount | 6-MFSOP, 4 Lead | UR |
