Signal Relays, Up to 2 Amps
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Part Status | Mounting Style | Coil Voltage | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Release Time | Coil Current | Coil Type | Contact Form | Features | Termination Style | Operate Time | Seal Rating | Operating Temperature | Must Release Voltage | Coil Insulation | Must Operate Voltage | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS2E-ML2-DC6VRELAY GENERAL PURPOSE DPDT 2A 6V |
2,486 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 6VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 60 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 4.2 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-ML2-DC9VRELAY GENERAL PURPOSE DPDT 2A 9V |
3,371 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 9VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 40 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 6.3 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC12V-RRELAY GEN PURPOSE DPDT 2A 12V |
4,399 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 16.7 mA | Non Latching | DPDT (2 Form C) | Reverse Polarity | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 1.2 VDC | - | 8.4 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC12V-TBRELAY GEN PURPOSE DPDT 2A 12V |
3,882 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 16.7 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 1.2 VDC | - | 8.4 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC24V-RRELAY GEN PURPOSE DPDT 2A 24V |
4,211 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 24VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 8.3 mA | Non Latching | DPDT (2 Form C) | Reverse Polarity | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 2.4 VDC | - | 16.8 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC24V-TBRELAY GEN PURPOSE DPDT 2A 24V |
4,407 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 24VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 8.3 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 2.4 VDC | - | 16.8 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC3VRELAY GENERAL PURPOSE DPDT 2A 3V |
4,404 |
|
Datasheet |
DS | Bulk | Obsolete | Through Hole | 3VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 66.7 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 0.3 VDC | - | 2.1 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC48V-TBRELAY GEN PURPOSE DPDT 2A 48V |
3,796 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 48VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 4.2 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 4.8 VDC | - | 33.6 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC5V-TBRELAY GENERAL PURPOSE DPDT 2A 5V |
3,769 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 40 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 0.5 VDC | - | 3.5 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC6V-RRELAY GENERAL PURPOSE DPDT 2A 6V |
2,458 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 6VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 33.3 mA | Non Latching | DPDT (2 Form C) | Reverse Polarity | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 0.6 VDC | - | 4.2 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC9VRELAY GENERAL PURPOSE DPDT 2A 9V |
4,987 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 9VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 22.2 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 0.9 VDC | - | 6.3 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC9V-RRELAY GENERAL PURPOSE DPDT 2A 9V |
3,554 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 9VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 22.2 mA | Non Latching | DPDT (2 Form C) | Reverse Polarity | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 0.9 VDC | - | 6.3 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-S-DC9V-TBRELAY GENERAL PURPOSE DPDT 2A 9V |
3,813 |
|
Datasheet |
DS | Tape & Box (TB) | Obsolete | Through Hole | 9VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 22.2 mA | Non Latching | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | 0.9 VDC | - | 6.3 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL-DC12VRELAY GEN PURPOSE DPDT 2A 12V |
3,402 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 7.5 mA | Latching, Single Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 8.4 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL-DC24VRELAY GEN PURPOSE DPDT 2A 24V |
3,571 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 24VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 3.8 mA | Latching, Single Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 16.8 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL-DC3VRELAY GENERAL PURPOSE DPDT 2A 3V |
2,651 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 3VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 30 mA | Latching, Single Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 2.1 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL-DC5VRELAY GENERAL PURPOSE DPDT 2A 5V |
3,541 |
|
Datasheet |
DS | Bulk | Obsolete | Through Hole | 5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 18 mA | Latching, Single Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 3.5 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL-DC9VRELAY GENERAL PURPOSE DPDT 2A 9V |
4,753 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 9VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 10 mA | Latching, Single Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 6.3 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL2-DC12V-RRELAY GEN PURPOSE DPDT 2A 12V |
2,140 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 12VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 15 mA | Latching, Dual Coil | DPDT (2 Form C) | Reverse Polarity | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 8.4 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
DS2E-SL2-DC1.5VRELAY GEN PURPOSE DPDT 2A 1.5V |
3,444 |
|
Datasheet |
DS | Tube | Obsolete | Through Hole | 1.5VDC | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 5 ms | 120 mA | Latching, Dual Coil | DPDT (2 Form C) | - | PC Pin | 10 ms | Sealed - Fully | -40°C ~ 70°C | - | - | 1.05 VDC | Silver (Ag), Gold (Au) | General Purpose | - | - |
