ams-OSRAM USA INC. LZ7-N4M100
- Part No.:
- LZ7-N4M100
- Manufacturer:
- ams-OSRAM USA INC.
- Category:
- LED COBs, Engines, Modules, Strips
- Package:
- Datasheet:
-
LZ7-N4M100.pdf
- Description:
- LED MOD LUXIGEN MULTI RECT SMD
- Quantity:
- Payment:
- Shipping:
Product details
- Specifications
- FAQ
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- ams-OSRAM USA INC.
- Series:
- LuxiGen™
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Obsolete
- Type:
- LED Module
- Color:
- Amber, Blue, Cyan, Green, Red, Violet, White - Cool
- CCT (K):
- 6500K
- Wavelength:
- 595nm Amber, 457nm Blue, 497nm Cyan, 525nm Green, 624nm Red, 395nm Violet, 6500K White
- Configuration:
- Rectangle
- Luminous Flux @ Current/Temperature:
- 70lm Amber, 33lm Blue, 101lm Cyan, 140lm Green, 80lm Red, 900mW Violet, 210lm White
- Current - Test:
- 700mA Amber, 700mA Blue, 700mA Cyan, 700mA Green, 700mA Red, 700mA Violet, 700mA White
- Temperature - Test:
- 25°C
- Voltage - Forward (Vf) (Typ):
- 2.5V Amber, 3.3V Blue, 3.45V Cyan, 3.7V Green, 2.5V Red, 3.7V Violet, 3.3V White
- Lumens/Watt @ Current - Test:
- 39 lm/W Amber, 14 lm/W Blue, 42 lm/W Cyan, 54 lm/W Green, 44 lm/W Red, 91 lm/W White
- Current - Max:
- 1A Amber, 1.5A Blue, 1A Cyan, 1.5A Green, 1.5A Red, 1A Violet, 1.5A White
- CRI (Color Rendering Index):
- 75 (Typ)
- Viewing Angle:
- 120°
- Features:
- -
- Size / Dimension:
- 38.30mm L x 31.20mm W
- Height:
- 2.41mm
- Light Emitting Surface (LES):
- -
- Lens Type:
- Flat
