Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Type | Material - Core | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Supplier Device Package | Shielding | DC Resistance (DCR) | Inductance | Q @ Freq | Frequency - Self Resonant | Mounting Style | Ratings | Size / Dimension | Features | Operating Temperature | Inductance Frequency - Test | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRP1235-R15MFIXED IND 150NH 41A 1.2 MOHM SMD Bourns Inc. |
3,541 |
|
Datasheet |
SRP1235 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Iron | ±20% | 41 A | 50A | - | Shielded | 1.2mOhm Max | 150 nH | - | 100MHz | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | - | -55°C ~ 150°C | 100 kHz | 0.146" (3.70mm) |
|
|
SRP1235-R22MFIXED IND 220NH 38.5A 1.3MOHM SM Bourns Inc. |
2,473 |
|
Datasheet |
SRP1235 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Iron | ±20% | 38.5 A | 50A | - | Shielded | 1.3mOhm Max | 220 nH | - | 94MHz | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | - | -55°C ~ 150°C | 100 kHz | 0.146" (3.70mm) |
|
|
SRP1235-R60MFIXED IND 600NH 29A 2.5 MOHM SMD Bourns Inc. |
2,744 |
|
Datasheet |
SRP1235 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Iron | ±20% | 29 A | 42A | - | Shielded | 2.5mOhm Max | 600 nH | - | 73MHz | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | - | -55°C ~ 150°C | 100 kHz | 0.146" (3.70mm) |
|
|
SRP1235-R82MFIXED IND 820NH 25A 3 MOHM SMD Bourns Inc. |
4,301 |
|
Datasheet |
SRP1235 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Iron | ±20% | 25 A | 38A | - | Shielded | 3mOhm Max | 820 nH | - | 65MHz | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | - | -55°C ~ 150°C | 100 kHz | 0.146" (3.70mm) |
|
SRP7030-6R2FMFIXED IND 6.2UH SMD Bourns Inc. |
2,270 |
|
Datasheet |
SRP7030F | Nonstandard | Tape & Reel (TR) | Active | - | Iron | ±20% | - | - | - | Shielded | - | 6.2 µH | - | - | Surface Mount | - | 0.299" L x 0.256" W (7.60mm x 6.50mm) | Flat Wire | -55°C ~ 125°C | 100 kHz | 0.126" (3.20mm) |
|
SRR1260-470YFIXED IND 47UH 2.6A 86 MOHM SMD Bourns Inc. |
2,448 |
|
Datasheet |
SRR1260 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 2.6 A | 2.5A | - | Shielded | 86mOhm Max | 47 µH | 22 @ 2.52MHz | 7.63MHz | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 125°C | 100 kHz | 0.256" (6.50mm) |
|
CM100505-10NJLFIXED IND 10NH 320MA 410MOHM SMD Bourns Inc. |
3,433 |
|
Datasheet |
CM100505 | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Alumina | ±5% | 320 mA | - | 0402 (1005 Metric) | Unshielded | 410mOhm Max | 10 nH | 8 @ 100MHz | 2.8GHz | Surface Mount | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - | -40°C ~ 100°C | 100 MHz | 0.024" (0.60mm) |
|
|
CM100505-12NJLFIXED IND 12NH 320MA 450MOHM SMD Bourns Inc. |
4,821 |
|
Datasheet |
CM100505 | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Alumina | ±5% | 320 mA | - | 0402 (1005 Metric) | Unshielded | 450mOhm Max | 12 nH | 8 @ 100MHz | 2.8GHz | Surface Mount | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - | -40°C ~ 100°C | 100 MHz | 0.024" (0.60mm) |
|
|
CM100505-15NJLFIXED IND 15NH 240MA 600MOHM SMD Bourns Inc. |
2,805 |
|
Datasheet |
CM100505 | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Alumina | ±5% | 240 mA | - | 0402 (1005 Metric) | Unshielded | 600mOhm Max | 15 nH | 8 @ 100MHz | 2.5GHz | Surface Mount | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - | -40°C ~ 100°C | 100 MHz | 0.024" (0.60mm) |
|
|
CM100505-18NJLFIXED IND 18NH 240MA 700MOHM SMD Bourns Inc. |
3,561 |
|
Datasheet |
CM100505 | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Alumina | ±5% | 240 mA | - | 0402 (1005 Metric) | Unshielded | 700mOhm Max | 18 nH | 8 @ 100MHz | 2.2GHz | Surface Mount | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - | -40°C ~ 100°C | 100 MHz | 0.024" (0.60mm) |
