Logic Output Optoisolators
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Part Status | Number of Channels | Inputs - Side 1/Side 2 | Common Mode Transient Immunity (Min) | Input Type | Output Type | Operating Temperature | Current - Output / Channel | Data Rate | Voltage - Isolation | Propagation Delay tpLH / tpHL (Max) | Rise / Fall Time (Typ) | Qualification | Voltage - Forward (Vf) (Typ) | Mounting Style | Grade | Current - DC Forward (If) (Max) | Voltage - Supply | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RV1S9960ACCSP-10YC#SC0HI-SPEED OPTOCPLR 8PIN LSDIP |
240 |
|
Datasheet |
- | 8-SOIC (0.543", 13.80mm Width) | Strip | Active | 1 | 1/0 | 50kV/µs | - | CMOS | -40°C ~ 110°C | 10 mA | 15Mbps | 7500Vrms | 60ns, 60ns | 5ns, 5ns | - | 1.55V | Surface Mount | - | 6mA | 2.7V ~ 5.5V | 8-LSDIP |
|
HCPL-2232#300OPTOISO 3.75KV PUSH PULL 8DIP GW |
464 |
|
Datasheet |
- | 8-SMD, Gull Wing | Tube | Active | 2 | 2/0 | 10kV/µs | DC | Push-Pull, Totem Pole | -40°C ~ 85°C | 25 mA | 5MBd | 3750Vrms | 300ns, 300ns | 30ns, 7ns | - | 1.5V | Surface Mount | - | 10mA | 4.5V ~ 20V | 8-DIP Gull Wing |
|
OLS500HIGH CMR, HIGH-SPEED LOGIC GATE |
883 |
|
Datasheet |
- | 6-CLCC | Tube | Active | 1 | 1/0 | 1kV/µs | DC | Open Collector, Schottky Clamped | -55°C ~ 125°C | 25 mA | 10Mbps | 1500VDC | 60ns, 60ns | - | - | 1.8V | Surface Mount | - | 40mA | 7V | 6-CLCC (6.22x4.32) |
|
HCPL-1930OPTOISO 1.5KV 2CH OPEN COL 16DIP |
36 |
|
Datasheet |
- | 16-DIP (0.300", 7.62mm) | Tube | Active | 2 | 2/0 | 1kV/µs | DC | Open Collector, Schottky Clamped | -55°C ~ 125°C | 25 mA | 10Mbps | 1500VDC | 100ns, 100ns | 30ns, 24ns | - | - | Through Hole | - | 60mA | 4.5V ~ 5.5V | 16-DIP |
|
HCPL-6430OPTOISO 1.5KV PUSH PULL 20LCCC |
37 |
|
Datasheet |
- | 20-CLCC | Tube | Active | 2 | 2/0 | 500V/µs | DC | Push-Pull, Totem Pole | -55°C ~ 125°C | 25 mA | 40Mbps | 1500VDC | 60ns, 60ns | 15ns, 10ns | - | 1.35V | Surface Mount | - | 10mA | 4.75V ~ 5.25V | 20-LCCC (8.89x8.89) |
|
HCPL-5230OPTOISO 1.5KV 2CH PUSH PULL 8DIP |
37 |
|
Datasheet |
- | 8-CDIP (0.300", 7.62mm) | Tube | Active | 2 | 2/0 | 1kV/µs | DC | Push-Pull, Totem Pole | -55°C ~ 125°C | 15 mA | 5MBd | 1500VDC | 350ns, 350ns | 45ns, 10ns | - | 1.3V | Through Hole | - | 8mA | 4.5V ~ 20V | 8-DIP |
|
|
HCPL-6230OPTOISO 1.5KV PUSH PULL 20LCCC |
39 |
|
Datasheet |
- | 20-CLCC | Tube | Active | 2 | 2/0 | 1kV/µs | DC | Push-Pull, Totem Pole | -55°C ~ 125°C | 15 mA | 5MBd | 1500VDC | 350ns, 350ns | 45ns, 10ns | - | 1.3V | Surface Mount | - | 8mA | 4.5V ~ 20V | 20-LCCC (8.89x8.89) |
|
HCPL-6651OPTOISO 1.5KV OPEN COLL 16FLATPK |
64 |
|
Datasheet |
- | 16-FlatPack | Tube | Active | 4 | 4/0 | 1kV/µs | DC | Open Collector, Schottky Clamped | -55°C ~ 125°C | 25 mA | 10MBd | 1500VDC | 100ns, 100ns | 35ns, 35ns | - | 1.5V | Surface Mount | - | 20mA | 4.5V ~ 5.5V | 16-FlatPack |
|
|
HCPL-5231#300OPTOISO 1.5KV PUSH PULL 8DIP GW |
112 |
|
Datasheet |
- | 8-SMD, Gull Wing | Bulk | Active | 2 | 2/0 | 1kV/µs | DC | Push-Pull, Totem Pole | -55°C ~ 125°C | 15 mA | 5MBd | 1500VDC | 350ns, 350ns | 45ns, 10ns | - | 1.3V | Surface Mount | - | 8mA | 4.5V ~ 20V | 8-DIP Gull Wing |
.JPG)
|
H11L2S(TA)-VOPTOISO 5KV OPEN COLLECTOR 6SMD |
1,906 |
|
Datasheet |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | 1 | 1/0 | - | DC | Open Collector | -55°C ~ 100°C | 50 mA | 1MHz | 5000Vrms | 4µs, 4µs | 100ns, 100ns | - | 1.15V | Surface Mount | - | 60mA | 3V ~ 16V | 6-SMD |
|
H11L3VMOPTOISO 4.17KV OPN COLL 6DIP |
193 |
|
Datasheet |
- | 6-DIP (0.300", 7.62mm) | Tube | Active | 1 | 1/0 | - | DC | Open Collector | -40°C ~ 85°C | 50 mA | 1MHz | 4170Vrms | 4µs, 4µs | 100ns, 100ns | - | 1.2V | Through Hole | - | 30mA | 3V ~ 15V | 6-DIP |
|
6N137SDVMOPTOISO 5KV 1CH OPEN COLL 8SMD |
977 |
|
Datasheet |
- | 8-SMD, Gull Wing | Tape & Reel (TR) | Active | 1 | 1/0 | 10kV/µs (Typ) | DC | Open Collector | -40°C ~ 100°C | 50 mA | 10Mbps | 5000Vrms | 75ns, 75ns | 30ns, 10ns | - | 1.45V | Surface Mount | - | 50mA | 4.5V ~ 5.5V | 8-SMD |
|
RV1S9213ACCSP-10YV#SC0OPTO COUPLER IN 5PIN SSOP |
2,605 |
|
Datasheet |
- | 5-SMD, Gull Wing | Strip | Active | 1 | 1/0 | 50kV/µs | DC | Open Collector, Schottky Clamped | -40°C ~ 125°C | 15 mA | 1Mbps | 5000Vrms | 750ns, 500ns | - | - | 1.56V | Surface Mount | - | 20mA | 4.5V ~ 25V | 5-LSSO |
|
RV1S9060ACCSP-10YC#SC0HI-SPEED OPTOCPLR LSO-5 |
2,102 |
|
Datasheet |
- | 6-SOIC (0.295", 7.50mm Width), 5 Leads | Strip | Active | 1 | 1/0 | 50kV/µs | - | CMOS | -40°C ~ 125°C | 10 mA | 15Mbps | 5000Vrms | 60ns, 60ns | 5ns, 5ns | - | 1.55V | Surface Mount | - | 6mA | 6V | 5-LSO |
|
H11L2SVMOPTOISO 4.17KV OPN COLL 6SMD |
1,846 |
|
Datasheet |
- | 6-SMD, Gull Wing | Tube | Active | 1 | 1/0 | - | DC | Open Collector | -40°C ~ 85°C | 50 mA | 1MHz | 4170Vrms | 4µs, 4µs | 100ns, 100ns | - | 1.2V | Surface Mount | - | 30mA | 3V ~ 15V | 6-SMD |
|
6N137VMOPTOISO 5KV 1CH OPEN COLL 8DIP |
371 |
|
Datasheet |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | 1 | 1/0 | 10kV/µs (Typ) | DC | Open Collector | -40°C ~ 100°C | 50 mA | 10Mbps | 5000Vrms | 75ns, 75ns | 30ns, 10ns | - | 1.45V | Through Hole | - | 50mA | 4.5V ~ 5.5V | 8-DIP |
|
|
ICPLW137SMT&ROPTOCOUPLER |
180 |
|
Datasheet |
- | 8-SMD, Gull Wing | Tape & Reel (TR) | Active | 1 | 1/0 | 10kV/µs | DC | Open Collector, Schottky Clamped | -40°C ~ 105°C | 50 mA | 10Mbps | 5000Vrms | 100ns, 100ns | 23ns, 10ns | - | 1.38V | Surface Mount | - | 20mA | 7V | 8-SMD |
|
|
VO2611OPTOISO 5.3KV OPEN DRAIN 8DIP |
1,761 |
|
Datasheet |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | 1 | 1/0 | 15kV/µs | DC | Open Drain | -40°C ~ 100°C | 50 mA | 10MBd | 5300Vrms | 100ns, 100ns | 23ns, 7ns | - | 1.4V | Through Hole | - | 20mA | 4.5V ~ 5.5V | 8-DIP |
|
FOD8173SSO6 3.3V 10MB |
1,860 |
|
Datasheet |
- | 6-SOIC (0.268", 6.80mm Width) | Tube | Active | 1 | 1/0 | 20kV/µs | DC | Push-Pull, Totem Pole | -40°C ~ 100°C | 10 mA | 20Mbps | 5000Vrms | 55ns, 55ns | 7ns, 7ns | - | 1.35V | Surface Mount | - | 20mA | 3V ~ 5.5V | 6-SOIC |
|
|
VO4661OPTOISO 5.3KV 2CH OPEN DRN 8DIP |
1,957 |
|
Datasheet |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | 2 | 2/0 | 15kV/µs | DC | Open Drain | -40°C ~ 100°C | 50 mA | 10MBd | 5300Vrms | 75ns, 75ns | 23ns, 7ns | - | 1.4V | Through Hole | - | 15mA | 4.5V ~ 5.5V | 8-DIP |
