Home > Products > Optoelectronics > LED Color Lighting

ams-OSRAM USA INC. LZ7-04M100

Name: LZ7-04M100
Brand: ams-OSRAM USA INC.
SKU: LZ7-04M100
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: LZ7-04M100

Manufacturer:: ams-OSRAM USA INC.

Category:: LED Color Lighting

Package:: 2828 (7070 Metric)

Datasheet:: LZ7-04M100.pdf

Description:: LED LUXIGEN MULT COLOR SMD

Quantity:: RFQ Add To RFQ list

Payment:

Shipping:

Product details

Specifications
FAQ
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: ams-OSRAM USA INC.

Series:: LuxiGen™

Package/Case:: 2828 (7070 Metric)

Packaging:: Tape & Reel (TR)

Product Status:: Obsolete

Color:: Amber, Blue, Cyan, Green, Red, Violet, White - Cool

Wavelength:: 595nm Amber, 457nm Blue, 497nm Cyan, 525nm Green, 624nm Red, 395nm Violet, 6500K White

Current - Test:: 700mA Amber, 700mA Blue, 700mA Cyan, 700mA Green, 700mA Red, 700mA Violet, 700mA White

Voltage - Forward (Vf) (Typ):: 2.5V Amber, 3.3V Blue, 3.45V Cyan, 3.7V Green, 2.5V Red, 3.7V Violet, 3.3V White

Lumens/Watt @ Current - Test:: 39 lm/W Amber, 14 lm/W Blue, 42 lm/W Cyan, 54 lm/W Green, 44 lm/W Red, 91 lm/W White

Current - Max:: 1A Amber, 1.5A Blue, 1A Cyan, 1.5A Green, 1.5A Red, 1A Violet, 1.5A White

Luminous Flux @ Current/Temperature:: 70lm Amber, 33lm Blue, 101lm Cyan, 140lm Green, 80lm Red, 900mW Violet, 210lm White

Temperature - Test:: 25°C

Viewing Angle:: 120°

Mounting Type:: Surface Mount

Supplier Device Package:: SMD

Size / Dimension:: 0.276" L x 0.276" W (7.00mm x 7.00mm)

Height - Seated (Max):: 0.044" (1.11mm)
